Supported processor sockets | LGA 1200 (Socket H5) |
Processor Socket | LGA 1200 (Socket H5) |
Compatible processor series | Intel® Core™ i7 |
Processor manufacturer | Intel |
Maximum Resolution | 4096 x 2304 pixels |
Number of displays supported | 2 |
Parallel processing technology support | Not supported |
HDCP | Yes |
Motherboard chipset family | Intel |
Windows operating systems supported | Windows 10 x64 |
Motherboard form factor | micro ATX |
Audio output channels | 7.1 channels |
PC health monitoring | Voltage |
MOTHERBOARD CHIPSET | Intel H510 Express |
Memory slots type | DIMM |
Number of memory slots | 2 |
Memory channels | Dual-channel |
Supported memory types | DDR4-SDRAM |
Supported memory clock speeds | 2933 |
Unbuffered memory | Yes |
Maximum internal memory | 64 GB |
Width | 226 mm |
Height | 52 mm |
Depth | 185 mm |
Ethernet interface type | Gigabit Ethernet |
Wi-Fi | No |
Ethernet LAN | Yes |
EPS power connector (8-pin) | Yes |
RGB LED pin header | Yes |
Front panel audio connector | Yes |
ATX Power connector (24-pin) | Yes |
TPM connector | Yes |
Front panel connector | Yes |
CPU fan connector | Yes |
Number of SATA III connectors | 4 |
Serial port headers | 1 |
Number of chassis fan connectors | 2 |
USB 2.0 connectors | 2 |
12V power connector | Yes |
USB 3.2 Gen 1 (3.1 Gen 1) connectors | 1 |
Desktop Management Interface (DMI) version | 2.7 |
BIOS Type | UEFI AMI |
Clear CMOS jumper | Yes |
Drivers included | Yes |
CABLES INCLUDED | SATA |
Number of storage drives supported | 5 |
Supported storage drive types | HDD & SSD |
Supported storage drive interfaces | M.2, PCI Express 3.0, SATA III |
USB connector type | USB Type-A |
PS/2 ports quantity | 2 |
Microphone in | Yes |
USB 3.2 Gen 1 (3.1 Gen 1) Type-A ports quantity | 2 |
HDMI ports quantity | 1 |
Ethernet LAN (RJ-45) ports | 1 |
HDMI version | 1.4 |
VGA (D-Sub) ports quantity | 1 |
USB 2.0 ports quantity | 4 |
PCI Express x1 slots | 2 |
Number of M.2 (M) slots | 1 |
PCI Express x16 slots | 1 |
Weight | 385 g |
