Lenovo ThinkCentre M75s SFF Gen5 is a business-class desktop computer built on powerful AMD technology. The slightly larger SFF chassis offers an extensive array of ports and multiple expansion slots. The Microsoft Pluton security processor enhances the resilience of ThinkCentre M75s SFF models against hardware and firmware attacks.
Key Features:
- Operating System: Windows 11 Pro 64-bit
- CPU: AMD Ryzen 7 8700G (8C/16T,4.2/5.1GHz,8MB/16MB)
- Chipset: AMD PRO665
- Memory: 16GB DDR5 5200MHz UDIMM (1x16)
- Memory capacity max.: 64GB (2x32)
- Integrated graphics: AMD Radeon 740M Graphics
- SSD 1TB M.2 2280 PCIe 4.0x4 NVMe Opal 2.0
- Additional Storage Support: 1x3.5"HDD and 1xM.2 2280
- Installation kits for additional drives must be purchased separately as an option
- Optical Drice: internal DVD+/-RW
- Card Reader: 3-in-1 (SD/SDHC/SDXC)
- Internal Speaker: 1x1W
- LAN: 100/1000M Gigabit Ethernet
- WLAN: one free M.2 Wi-Fi slot
- Lenovo USB keyboard and USB Mouse included
- Front panel: 4xUSB-A 3.2 Gen1, 1xUSB-C 3.2 Gen1, 1x3.5mm audio combo, 1x3.5mm Mic
- Back panel: 2xDisplayPort 1.4a, HDMI 2.1 TMDS, 4xUSB2.0, 1xRS232, RJ-45, 1x3.5mm Line Out
- Low Profile Expansion Slots: 1xPCIe 3.0 x1, 1xPCIe 3.0 x16
- LP Card max. Size: =155mm (length), =70mm (height)
- Security chip: TPM 2.0 (TCG ja FIPS 140-2 certified)
- Security CPU: Microsoft Pluton
- Kensington® Security Slot™ (3x7mm)
- Internal PSU: 260W 90%
- Military-Grade Durability: MIL-STD-810H
- Standard warranty: 3Y on-site
- Weight: 4.6kg
Lenovo CO2 Offset Gen2 Emission Compensation
- The carbon dioxide emissions generated from the production, transportation, and electricity consumed throughout the lifecycle of this device have been offset through the global Climeco organization in approved UN environmental projects.
Environmental and Energy Certifications
- ENERGY STAR® 8.0, EPEAT™ Gold Registered, ErP Lot 3, GREENGUARD®, RoHS compliant, TCO Certified 9.0
Product life cycle used in emission assessments, years | 4 |
Manufacturing-related CO2 emissions, kg (manufacturer?s estimate) | 314.7 |
Product life cycle CO2 emissions, kg (manufacturer?s estimate) | 479 |
Operatsioonisüsteem (komplektis) | Windows 11 Pro |
Liidesed | USB-C (Gen1) |
Sisseehitatud mälu | 16 GB |
Pooljuhtketta tüüp | M.2 PCIe NVMe |
Paigaldatud mälu maksimaalne maht, GB | 64 GB |
Emaplaadi kiibistik | AMD PRO665 |
Mälupesad (vabad) | 2 |
Vooluadapter, W | 290 |
Protsessori tootja | AMD |
Mõõtmed W x D x H, mm | 92.5 x 297.7 x 339.5 |
Paigaldatud mälutüüp | DDR5 |
Kaal, g | 4600 |
Mälu taktsagedus, MHz | 5200 |
Ethernet LAN (RJ-45) portide arv | 1 |
USB-A (USB 3.2) portide arv | 4 |
HDMI portide arv | 1 |
Mälupesad | 2 |
DisplayPorts portide arv | 2 |
USB-C (USB 3.2) ports quantity | 1 |
USB-A (USB 2.0) portide arv | 4 |
Green certifications | TCO 9.0 |
L3 vahemälu, MB | 16 |
PCI Express x16 | 1 |
PCI Express x1 | 1 |
Protsessori seeria | AMD Ryzen 7 |
Protsessori tuumade arv | 8 |
Salvestusmaht | 1 TB SSD |
Graafika adapter | AMD Radeon 780M |
Protsessori taktsagedus, GHz | 4.20 |
Protsessori mudel | AMD Ryzen 7 8700G (Max. 5.1GHx, 16MB, 8C) |
RAID-i kontroller | No |
Juhtmeta LAN (WLAN) | No |
Optiline seadme | Yes |
Sisseehitatud kaardilugeja | Yes |
Bluetooth (sinihammas) | No |
Spetsiaalne videomälu (GB) | Uses system memory |
