The Lenovo ThinkVision 27 3D monitor offers an astonishing and immersive 3D experience without the need for 3D glasses, using real-time eye tracking. With excellent image brightness and sharpness, and 3D models that appear naturally smooth without reducing the refresh rate, the viewing models do not strain the eyes.
When not working with 3D models, the monitor provides an excellent traditional 2D experience with sharp 4K resolution, full AdobeRGB color gamut, and HDR support. You can seamlessly switch between 2D and 3D modes. The monitor features USB-C docking capabilities and the option to add Lenovo’s modular MC60 webcam with Windows Hello support.
Lenovo’s 3D ecosystem provides the best and rapidly evolving tools to enhance productivity and creativity with software such as 3ds Max, VRED, Creo, and Office365. The integrated 3D processor offloads 3D processing to the monitor, reducing the load on the terminal device and delivering optimal performance from your computer.
The ThinkVision 27 3D is a revolutionary product for design work, and its benefits can only be fully appreciated by experiencing it firsthand. F9 allows you to do this with their demo unit and expert guidance; inquire about available demo times at lenovo@f9.fi.
Key Features:
- Screen Size: 27"
- Panel Type: IPS
- Resolution: 3840x2160 (1920x2160 in 3D mode)
- Pixel Per Inch: 163 dpi
- Aspect Ratio: 16:9
- Refresh Rate: 60 Hz
- Brightness: 310 cd/m²
- Contrast Ratio: 2000:1
- Dynamic Contrast: 3M:1
- HDR10 Decoding
- Color Gamut: 99% DCI-P3, 100% AdobeRGB
- Color Depth: 8-bit
- Typical Response Time: 6 ms (4ms in extreme mode)
- Viewing Angle (H/V): 178°/178°
- Factory Calibration: Avg. Delta E<1
- Built-in Speakers: 2x5W
- Support for Modular MC60 Webcam
- Connections: 1x USB-C 3.2 (DP 1.4 Alt Mode), 2x HDMI 2.1 TDMS, DP 1.4, 1x USB-C 3.2 (15W), 4x USB 3.2, RJ45, Audio Out (3.5mm)
- USB-C Charging Power: Max. 100W
- Stand Adjustments: Tilt, Swivel, Height Adjustment, Pivot
- VESA Mount Support: (100 mm)
- Kensington Lock Slot
- Headphone and Phone Stand
- Included Cables: USB-C to USB-C (1.5m), DP to DP (1.8m), HDMI to HDMI (1.8m), USB-C to USB-A (1.8m), Power Cable (1.8m)
- Typical Power Consumption: 43.8W
- Weight: 8.9 kg
- Three-Year Replacement Warranty
3D Features:
- 2D/3D Mode< Switch°
- 3D Resolution: 1920x2160°
- Eye Tracking°
- Number of Simultaneous Users: 1°
- ptimal Viewing Distance: 70-90 cm°
- Optimal Viewing Angle: +/- 20°/20°
Software:
- 3D Explorer (Available for download from Lenovo Accessories and Display Manager app)
- 3D Explorer Plugins (Creo, 3ds Max, M365)
- 3D Master (3D Viewer app)
- Design Engine
- 2D-to-3D Converter
- SDK Developer Tools
Third-Party Software Support (Updated May 20, 2024):
- Microsoft 365, PTC Creo, Autodesk 3ds Max, Autodesk VRED, Autodesk Maya, Trimble SketchUp Pro, Blender, Lumiscaphe Patchwork 3D, Dassault Systems Deltagen, Unity, C++ & Unreal (via SDK)
Hardware Requirements:
- CPU: i5-7400 (3GHz)
- RAM: 8GB
- Graphics Card: NVIDIA® GeForce GTX 1050 or better
- OS: Windows 10 64-bit
- Free Storage Space: 50GB
Environmental and Energy Certifications:
- RoHS, EU Energy Efficiency Level (Level-G)
Ergonomic Certifications:
- TÜV Rheinland® Eye Comfort
Recycling-related CO2 emissions, kg (manufacturer?s estimate) | 10 |
Product life cycle CO2 emissions, kg (manufacturer?s estimate) | 635 |
CO2 emissions during use, kg (manufacturer?s estimate) | 201 |
Product life cycle used in emission assessments, years | 4 |
Manufacturing-related CO2 emissions, kg (manufacturer?s estimate) | 350.42 |
Transportation-related CO2 emissions, kg (manufacturer?s estimate) | 65.7 |
Product packaging CO2 emissions, kg (manufacturer?s estimate) | 7.88 |
Ekraani diagonaal, " | 27 |
Liidesed | Ethernet (RJ-45) |
Ekraani resolutsioon, pikslit | 3840x2160(2D), 1920x2160(3D) |
Ekraani heledus, cd/m² | 310 |
Kontrastsuse suhe (tavaline) | 1200:1 |
Kuva suhe | 16:9 |
Kõlari võimsus, W | 10 |
VESA-standard, mm | 100 x 100 |
Paneeli tüüp | IPS |
Reageerimisaeg, ms | 6 |
Värskendussagedus, Hz | 60 |
Energiatõhususe klass | G |
Vaatenurk, vertikaalne, ° | 178 |
Vaatenurk, horisontaalne, ° | 178 |
Energiatarbimine, W | 43.8 |
Kuvatavate värvide arv | 16.7 M |
Kaal koos alusega, g | 8900 |
Kaal, g | 6600 |
Mõõtmed W x D x H, mm | 614.8 x 72.3 x 390 |
Mõõtmed (L x S x K) jalaga, mm | 614.8 x 222.7 x 413 |
Energiatarve (maks.), W | 246 |
Green certifications | EU Energy Efficiency Level (Level-G) |
Kõverdatud | No |
Jala kõrguse muutmine | Yes |
Puutetundlik ekraanipind | No |
PIVOT funktsioon | Yes |
Sisseehitatud kõlarid | Yes |
Läikiv ekraanipind | No |
