screen | |
screen size | 48,3 cm (19") |
Display resolution | 1280 x 1024 Pixel |
HD-Typ | SXGA |
Native Aspect Ratio | 5:4 |
screen technology | LCD |
Panel-Typ | IPS |
Backlight type | LED |
brightness (typical) | 250 cd/m² |
reaction time | 6 ms |
screen shape | Flach |
Supported graphic resolutions | 1280 x 1024 (SXGA) |
contrast ratio | 1000:1 |
Contrast Ratio (dynamic) | 4000000:1 |
Maximum refresh rate | 60 Hz |
angle of view, horizontal | 178° |
angle of view, vertical | 178° |
Number of colors of the display | 16,78 Millionen Farben |
pixels spacing | 0,293 x 0,293 mm |
pixel density | 86 ppi |
Horizontal scan area | 30 - 81 kHz |
Vertical scan area | 56 - 76 Hz |
Visible size (horizontal) | 37,5 cm |
Visible size (vertical) | 30 cm |
Visible size (diagonal) | 48 cm |
Design | |
market positioning | Haus |
Product color | Schwarz |
connections and interfaces | |
Eigenschaft | Ständer enthalten |
USB-Hub-Version | 3.2 Gen 1 (3.1 Gen 1) |
USB-Upstream-Porttyp | USB Typ-B |
Number of upstream slots | 1 |
Number of downstream USB-A type slots | 4 |
Number of VGA (D-Sub) connections | 1 |
Number of HDMI ports | 1 |
Number of DisplayPort connections | 1 |
Ergonomics | |
Panel mounting interface | 100 x 100 mm |
Einstellbare Höhe (max.) | 13 cm |
Pivot Store | -90 - 90° |
swivel angle range | -45 - 45° |
tilt angle range | -5 - 21° |
energy | |
Energy efficiency class (SDR) | D |
Energy efficiency class (HDR) | Nicht verfügbar |
Energy consumption (SDR) per 1,000 hours | 11 kWh |
Power consumption (standard operation) | 14 W |
Power consumption (standby) | 0,3 W |
Power consumption (max.) | 38 W |
power consumption (off) | 0,3 W |
Power consumption (PowerSave) | 13 W |
AC input voltage | 100 - 240 V |
AC input frequency | 50 - 60 Hz |
input current | 1.5 A |
power supply type | Intern |
annual energy consumption | 17 kWh |
operating conditions | |
operating temperatur | 0 - 40 °C |
Storage temperature range | -20 - 60 °C |
Operating relative humidity | 20 - 80% |
humidity during storage | 10 - 90% |
operating height | 0 - 5000 m |
storage height | 5000 - 12192 m |
weight and dimensions | |
Gerätebreite (inkl. Standfuß) | 405,6 mm |
Gerätetiefe (inkl. Standfuß) | 180 mm |
Gerätehöhe (inkl. Standfuß) | 499,3 mm |
Gewicht (inklusive Standfuß) | 5,13 kg |
Width (without stand) | 405,6 mm |
Depth (without stand) | 50,3 mm |
Height (without stand) | 334,3 mm |
Gewicht (ohne Standfuß) | 2,6 kg |
scope of delivery | |
Supplied cables | AC, DisplayPort, USB, VGA |
sustainability | |
sustainability certificates | ENERGY STAR |
CO2-Fußabdruck | |
Gesamter Kohlendioxid-Fußabdruck (kg of CO2e) | 433 |
Kohlenstoffemissionen insgesamt, Standardabweichung (kg an CO2e) | 86 |
Kohlenstoffemissionen, Herstellung (kg an CO2e) | 310 |
Kohlenstoffemissionen, Logistik (kg an CO2e) | 39 |
Kohlenstoffemissionen, Energieverbrauch (kg an CO2e) | 83 |
Kohlenstoffemissionen, Ende der Lebensdauer (kg an CO2e) | 2 |
Kohlenstoffemissionen gesamt, mit/ohne Nutzungsphase(kg an CO2e) | 351 |
PAIA-Version | 9/5/2018 |
Other functions | |
Display | LED |
Energy efficiency class (old) | A+ |
Compliance with industry standards | TCO |
