screen | |
screen size | 60,5 cm (23.8") |
Display resolution | 1920 x 1080 Pixel |
HD-Typ | Full HD |
Native Aspect Ratio | 16:9 |
screen technology | LCD |
Panel-Typ | TFT |
Eigenschaft | Anschluß zu PC |
Type of touch screen | Tisch |
Touchscreen Technology | Projizierts Kapazitivsystem |
Touch technology | Multitouch |
Number of simultaneous touchpoints | 10 |
brightness (typical) | 450 cd/m² |
brightness | 300 cd/m² |
reaction time | 14 ms |
screen shape | Flach |
Supported graphic resolutions | 1920 x 1080 (HD 1080) |
contrast ratio | 4000:1 |
Contrast Ratio (dynamic) | 10000000:1 |
Maximum refresh rate | 60 Hz |
angle of view, horizontal | 178° |
angle of view, vertical | 178° |
Number of colors of the display | 16,7 Millionen Farben |
pixels spacing | 0,2745 x 0,2745 mm |
Horizontal scan area | 31 - 83 kHz |
Vertical scan area | 56 - 75 Hz |
screen size (cm) | 60,45 cm |
surface hardness | 7H |
Services | |
Smart-Modi | Spiel, Film, PC |
Supports Windows operating systems | Windows 10, Windows 7, Windows 8 |
Multimedia | |
number of speakers | 2 |
RMS performance | 3 W |
Design | |
market positioning | Professionell |
Product color | Schwarz |
front frame | Schwarz |
Glasdicke | 1,2 mm |
connections and interfaces | |
USB-Hub-Version | 3.2 Gen 1 (3.1 Gen 1) |
USB-Upstream-Porttyp | USB Typ-B |
Number of upstream slots | 1 |
Number of USB Type-B upstream ports | 1 |
Number of downstream USB-A type slots | 2 |
USB Touch Anzahl Ports | 1 |
Number of VGA (D-Sub) connections | 1 |
Number of HDMI ports | 1 |
Number of DisplayPort connections | 1 |
Ergonomics | |
Panel mounting interface | 100 x 100 mm |
Lock-Type Cable Barrier | Kensington |
tilt angle range | 15 - 70° |
Number of OSD languages | 15 |
energy | |
Energy efficiency class (SDR) | D |
Energy consumption (SDR) per 1,000 hours | 14 kWh |
Power consumption (standard operation) | 18 W |
Power consumption (standby) | 0,3 W |
power consumption (off) | 0,3 W |
AC input voltage | 100 - 240 V |
AC input frequency | 50 - 60 Hz |
power supply output voltage | 12 V |
power supply type | Gleichstrom |
energy efficiency scale | A bis G |
operating conditions | |
operating temperatur | 5 - 35 °C |
Operating relative humidity | 20 - 85% |
weight and dimensions | |
Width (without stand) | 549,8 mm |
Depth (without stand) | 49,1 mm |
Height (without stand) | 333,2 mm |
Gewicht (ohne Standfuß) | 4,5 kg |
package weight | 6,1 kg |
scope of delivery | |
Supplied cables | AC, HDMI, USB |
Other functions | |
Unterstützte Positionierung | Horizontal/Vertikal |
Konformitätsbescheinigungen | RoHS |
certification | CE, HDMI, EPA7.0, WIN10 |
logistic data | |
Goods tariff number (HS) | 85285210 |
