| screen | |
| screen size | 48,3 cm (19") |
| Display resolution | 1280 x 1024 Pixel |
| HD-Typ | SXGA |
| Native Aspect Ratio | 5:4 |
| screen technology | LED |
| Panel-Typ | IPS |
| Eigenschaft | Anschluß zu PC |
| Backlight type | LED |
| Touchscreen Technology | Projizierts Kapazitivsystem |
| Touch technology | Multitouch |
| brightness | 350 cd/m² |
| reaction time | 14 ms |
| screen shape | Flach |
| Supported graphic resolutions | 1280 x 1024 (SXGA) |
| aspect ratio | 5:4 |
| Contrast Ratio (dynamic) | 1000:1 |
| angle of view, horizontal | 178° |
| angle of view, vertical | 178° |
| Number of colors of the display | 16,78 Millionen Farben |
| pixels spacing | 0,294 x 0,294 mm |
| Horizontal scan area | 31,4 - 80 kHz |
| Visible size (horizontal) | 30,1 cm |
| Visible size (vertical) | 37,6 cm |
| Visible size (diagonal) | 48 cm |
| screen size (cm) | 48 cm |
| Design | |
| Product color | Schwarz |
| Glasdicke | 6 mm |
| connections and interfaces | |
| Number of VGA (D-Sub) connections | 1 |
| Number of HDMI ports | 1 |
| Number of DisplayPort connections | 1 |
| Ergonomics | |
| Panel mounting interface | 100 x 100 mm |
| menu languages | Deutsch, Englisch, Spanisch, Französisch, Italienisch, Japanisch |
| Number of OSD languages | 7 |
| energy | |
| Energy efficiency class (SDR) | F |
| Energy consumption (SDR) per 1,000 hours | 18 kWh |
| Power consumption (standard operation) | 21 W |
| Power consumption (standby) | 1,5 W |
| power consumption (off) | 1,5 W |
| power supply type | Gleichstrom |
| energy efficiency scale | A bis G |
| weight and dimensions | |
| Width (without stand) | 416 mm |
| Depth (without stand) | 46,5 mm |
| Height (without stand) | 344 mm |
| Gewicht (ohne Standfuß) | 4,4 kg |
| Other functions | |
| International degree of protection (IP code) | IP65 |
| Display, visible area WxH | 376,5 x 301,1 mm |
| certification | CE, EAC, RoHS support, ErP, WEEE, cULus, REACH, REACH SVHC above 0.1%: Lead |
| logistic data | |
| Goods tariff number (HS) | 85285210 |
