| screen | |
| Panel-Typ | ELED |
| screen size | 80 cm (31.5") |
| screen technology | LED |
| Display resolution | 1920 x 1080 Pixel |
| brightness | 500 cd/m² |
| HD-Typ | Full HD |
| Native Aspect Ratio | 16:9 |
| reaction time | 8 ms |
| contrast ratio | 4000:1 |
| angle of view, horizontal | 178° |
| angle of view, vertical | 178° |
| Number of colors of the display | 16,7 Millionen Farben |
| Active display area (W x H) | 698,4 x 392,85 mm |
| screen size (cm) | 80 cm |
| Horizontal scan area | 28 - 160 kHz |
| Wiederholfrequenz | 60 Hz |
| connections and interfaces | |
| Number of HDMI ports | 3 |
| HDMI-Version | 2.0 |
| Eigenschaft | Montageset |
| Number of USB ports | 2 |
| USB-Version | 2.0 |
| Number of Ethernet LAN ports (RJ-45) | 1 |
| Audio input (L, R) | 1 |
| Audio (L,R) out | 1 |
| Remote control (IR) input | 1 |
| Audio | |
| Number of built-in speakers | 2 |
| RMS performance | 10 W |
| Design | |
| product design | Digitale A-Platine |
| Unterstützte Positionierung | Drinnen |
| alignment | Horizontal/Vertikal |
| Product color | Schwarz |
| Panel mounting interface | 200 x 150 mm |
| Rahmenbreite (unten) | 9 mm |
| Rahmenbreite (Seite) | 9 mm |
| Rahmenbreite (oben) | 9 mm |
| Services | |
| purpose | Universal |
| menu languages | Vereinfachtes Chinesisch, Tschechisch, Deutsch, Englisch, Spanisch, Französisch, Italienisch, Japanisch, Polnisch, Russisch |
| Operating times (hours/days) | 24/7 |
| HDCP-Version | 1.4/2.2 |
| Mean Time Between Failures (MTBF) | 50000 h |
| energy | |
| Power consumption (standard operation) | 40 W |
| Power consumption (standby) | 0,5 W |
| Energy efficiency class (SDR) | G |
| AC input voltage | 100 - 240 V |
| AC input frequency | 50 Hz |
| computer system | |
| processor manufacturer | ARM |
| processor family | ARM Cortex |
| processor | A53 |
| number of CPU cores | 4 |
| storage capacity | 2 GB |
| Eingebautes Grafikkartenmodell | ARM Mali-G52 |
| Internal storage capacity | 16 GB |
| Installed operating system | Android 11 |
| weight and dimensions | |
| Displaybreite | 724,6 mm |
| display depth | 40 mm |
| display height | 419,8 mm |
| Display weight | 5,4 kg |
| package weight | 7,3 kg |
| scope of delivery | |
| Supplied cables | HDMI, Leistung, RS-232 |
| operating conditions | |
| operating temperatur | 0 - 40 °C |
| Storage temperature range | -20 - 60 °C |
| certificates | |
| certification | CB, CE, TÜV-Bauart, EAC, RoHS support, ErP, WEEE, REACH, UKCA |
