Processor Socket | LGA 1700 |
Compatible processor series | Intel® Pentium® |
Processor manufacturer | Intel |
Maximum number of SMP processors | 1 |
HDCP | Yes |
Parallel processing technology support | Not supported |
Maximum Resolution | 4096 x 2160 pixels |
Audio output channels | 7.1 channels |
Windows operating systems supported | Windows 11 x64 |
audio chip | Realtek ALC887 / Realtek ALC897 |
Motherboard form factor | micro ATX |
MOTHERBOARD CHIPSET | Intel H610 |
PC health monitoring | Fan |
Motherboard chipset family | Intel |
Maximum internal memory | 64 GB |
Unbuffered memory | Yes |
Supported memory clock speeds | 3200 MHz |
Number of memory slots | 2 |
Supported memory types | DDR4-SDRAM |
Depth | 188 mm |
Width | 197 mm |
LAN controller | Realtek RTL8111H |
Wake-on-LAN ready | Yes |
Wi-Fi | No |
Ethernet interface type | Gigabit Ethernet |
Ethernet LAN | Yes |
Front panel audio connector | Yes |
USB 2.0 connectors | 1 |
USB 3.2 Gen 1 (3.1 Gen 1) connectors | 1 |
ATX Power connector (24-pin) | Yes |
TPM connector | Yes |
Number of chassis fan connectors | 1 |
Chassis intrusion connector | Yes |
Number of M.2 (M) slots | 1 |
Number of SATA III connectors | 4 |
12V power connector | Yes |
BIOS Type | UEFI AMI |
CABLES INCLUDED | SATA |
Drivers included | Yes |
Supported storage drive types | HDD & SSD |
Supported storage drive interfaces | SATA III |
USB 2.0 ports quantity | 4 |
USB 3.2 Gen 1 (3.1 Gen 1) Type-A ports quantity | 2 |
HDMI ports quantity | 1 |
Ethernet LAN (RJ-45) ports | 1 |
PS/2 ports quantity | 1 |
VGA (D-Sub) ports quantity | 1 |
HDMI version | 2.1 |
PCI Express x1 (Gen 3.x) slots | 1 |
PCI Express x16 (Gen 4.x) slots | 1 |
