Compatible processor series | Intel® Pentium® |
Processor manufacturer | Intel |
Processor Socket | LGA 1700 |
Maximum number of SMP processors | 1 |
Maximum Resolution | 7680 x 4320 pixels |
HDCP | Yes |
MOTHERBOARD CHIPSET | Intel H670 |
audio chip | Realtek ALC897 |
Motherboard chipset family | Intel |
Motherboard form factor | micro ATX |
PC health monitoring | Temperature |
Audio output channels | 7.1 channels |
Harmonized System (HS) code | 84733020 |
Memory channels | Dual-channel |
Supported memory clock speeds | 4800 |
Maximum internal memory | 128 GB |
Unbuffered memory | Yes |
Number of memory slots | 4 |
Memory slots type | DIMM |
Supported memory types | DDR4-SDRAM |
Width | 244 mm |
Depth | 244 mm |
LAN controller | Intel® I219-V |
Wake-on-LAN ready | Yes |
Wi-Fi | No |
Ethernet LAN | Yes |
Ethernet interface type | Gigabit Ethernet |
Number of SATA III connectors | 4 |
USB 3.2 Gen 1 (3.1 Gen 1) connectors | 2 |
ATX Power connector (24-pin) | Yes |
TPM connector | Yes |
Number of chassis fan connectors | 3 |
CPU fan connector | Yes |
Chassis intrusion connector | Yes |
Front panel audio connector | Yes |
Thunderbolt headers | 1 |
USB 2.0 connectors | 2 |
RGB LED pin header | Yes |
12V power connector | Yes |
BIOS Type | UEFI AMI |
Drivers included | Yes |
CABLES INCLUDED | SATA |
Supported storage drive interfaces | M.2, SATA III |
Supported storage drive types | HDD & SSD |
RAID levels | 5 |
Raid Support | Yes |
DisplayPort version | 1.4 |
Ethernet LAN (RJ-45) ports | 1 |
USB 3.2 Gen 2 (3.1 Gen 2) Type-A ports quantity | 2 |
DisplayPorts quantity | 1 |
HDMI ports quantity | 1 |
HDMI version | 2.1 |
USB 3.2 Gen 1 (3.1 Gen 1) Type-A ports quantity | 4 |
Number of M.2 (M) slots | 2 |
PCI Express x16 slots | 2 |
PCI Express x1 (Gen 3.x) slots | 1 |
