Supported processor sockets | Socket AM4 |
Compatible processor series | 3rd Generation AMD Ryzen™ 7 |
Processor manufacturer | AMD |
Maximum number of SMP processors | 1 |
Processor Socket | Socket AM4 |
On-board graphics card | No |
Parallel processing technology support | 2-Way CrossFireX |
Windows operating systems supported | Windows 10 Pro x64 |
Power source type | ATX |
Cooling type | Active |
Component for | PC |
MOTHERBOARD CHIPSET | AMD B550 |
PC health monitoring | CPU |
Audio output channels | 7.1 channels |
Motherboard chipset family | AMD |
Product colour | Black |
Motherboard form factor | ATX |
Supported memory types | DDR4-SDRAM |
Supported memory clock speeds | 3000 |
Number of memory slots | 4 |
Memory slots type | DIMM |
Maximum internal memory | 128 GB |
Width | 305 mm |
Height | 68 mm |
Depth | 244 mm |
Bluetooth Version | 5.0 |
LAN controller | Intel I225-V |
Ethernet interface type | 2.5 Gigabit Ethernet |
Wi-Fi | No |
Wake-on-LAN ready | Yes |
Ethernet LAN | Yes |
Bluetooth | Yes |
Number of chassis fan connectors | 3 |
EPS power connector (8-pin) | Yes |
USB 3.2 Gen 2 (3.1 Gen 2) connectors | 1 |
12V power connector | Yes |
CPU fan connector | Yes |
Number of EATX power connectors | 1 |
USB 3.2 Gen 1 (3.1 Gen 1) connectors | 1 |
Thunderbolt headers | 1 |
Number of SATA III connectors | 6 |
USB 2.0 connectors | 2 |
BIOS memory size | 256000 Mbit |
BIOS Type | UEFI AMI |
Manual | Yes |
Drivers included | Yes |
CABLES INCLUDED | SATA |
RAID levels | 0 |
Supported storage drive interfaces | M.2, SATA III |
Raid Support | Yes |
Number of HDDs supported | 6 |
Supported storage drive types | HDD & SSD |
USB 2.0 ports quantity | 2 |
HDMI ports quantity | 1 |
USB 3.2 Gen 2 (3.1 Gen 2) Type-A ports quantity | 1 |
USB 3.2 Gen 2 (3.1 Gen 2) Type-C ports quantity | 1 |
Ethernet LAN (RJ-45) ports | 1 |
Microphone in | Yes |
USB 3.2 Gen 1 (3.1 Gen 1) Type-A ports quantity | 4 |
HDMI version | 2.1 |
DisplayPort version | 1.2 |
Headphone outputs | 1 |
DisplayPorts quantity | 1 |
S/PDIF out port | Yes |
PCI Express x1 (Gen 3.x) slots | 3 |
Number of M.2 (M) slots | 2 |
PCI Express x16 (Gen 3.x) slots | 1 |
PCI Express x16 (Gen 4.x) slots | 1 |
PCI Express slots version | 3.0 |
PCI SLOTS | 7 |
Weight | 945 g |
Harmonized System (HS) code | 84733020 |
