Compatible processor series | 3rd Generation AMD Ryzen 5 |
Processor manufacturer | AMD |
Processor Socket | Socket AM4 |
Motherboard chipset family | AMD |
audio chip | Realtek ALC887 |
Motherboard form factor | micro ATX |
MOTHERBOARD CHIPSET | AMD B450 |
Audio output channels | 7.1 channels |
Windows operating systems supported | Windows 7 x64 |
Number of memory slots | 4 |
Supported memory clock speeds | 2400 |
Memory channels | Dual-channel |
Memory slots type | DIMM |
Supported memory types | DDR4-SDRAM |
Maximum internal memory | 128 GB |
Unbuffered memory | Yes |
Depth | 244 mm |
Width | 244 mm |
Ethernet LAN | Yes |
Ethernet interface type | Gigabit Ethernet |
Wi-Fi | No |
12V power connector | Yes |
RGB LED pin header | Yes |
Audio connector | Yes |
TPM connector | Yes |
CPU fan connector | Yes |
USB 3.2 Gen 1 (3.1 Gen 1) connectors | 1 |
Number of COM connectors | 1 |
Number of chassis fan connectors | 2 |
Number of SATA III connectors | 6 |
S/PDIF out connector | Yes |
EPS power connector (8-pin) | Yes |
Front panel audio connector | Yes |
USB 2.0 connectors | 2 |
ATX Power connector (24-pin) | Yes |
BIOS Type | UEFI AMI |
CABLES INCLUDED | SATA |
Number of storage drives supported | 7 |
RAID levels | 0 |
Supported storage drive interfaces | M.2, SATA, SATA II, SATA III |
USB 3.2 Gen 1 (3.1 Gen 1) Type-C ports quantity | 1 |
Microphone in | Yes |
PS/2 ports quantity | 1 |
Headphone outputs | 1 |
HDMI ports quantity | 1 |
DVI-D ports quantity | 1 |
USB 3.2 Gen 1 (3.1 Gen 1) Type-A ports quantity | 2 |
USB 3.2 Gen 2 (3.1 Gen 2) Type-A ports quantity | 1 |
Ethernet LAN (RJ-45) ports | 1 |
USB 2.0 ports quantity | 2 |
PCI Express x1 (Gen 2.x) slots | 1 |
PCI Express x16 (Gen 2.x) slots | 3 |
