Supported processor sockets | Socket AM5 |
Compatible processor series | AMD Ryzen 7000 Series |
Processor manufacturer | AMD |
Processor Socket | Socket AM5 |
Parallel processing technology support | Not supported |
On-board graphics card | No |
audio chip | Realtek ALC1220P |
Motherboard chipset family | AMD |
Motherboard form factor | micro ATX |
Product colour | Black |
MOTHERBOARD CHIPSET | AMD B850 |
Audio output channels | 7.1 channels |
Windows operating systems supported | Windows 10 x64 |
ECC сompatibility | ECC & Non-ECC |
Supported memory types | DDR5-SDRAM |
Maximum internal memory | 192 GB |
Memory slots type | DIMM |
Number of memory slots | 4 |
Memory channels | Dual-channel |
Unbuffered memory | Yes |
Depth | 244 mm |
Width | 244 mm |
Wi-Fi | Yes |
Ethernet LAN | Yes |
Wi-Fi standards | Wi-Fi 6E (802.11ax) |
Top Wi-Fi standard | Wi-Fi 6E (802.11ax) |
Bluetooth Version | 5.3 |
Ethernet interface type | 2.5 Gigabit Ethernet |
Bluetooth | Yes |
S/PDIF out connector | Yes |
Number of COM connectors | 1 |
Front panel connector | Yes |
ATX Power connector (24-pin) | Yes |
12V power connector | Yes |
Number of chassis fan connectors | 3 |
Number of SATA III connectors | 4 |
USB 3.2 Gen 1 (3.1 Gen 1) connectors | 1 |
CPU fan connector | Yes |
Chassis intrusion connector | Yes |
Front panel audio connector | Yes |
USB 2.0 connectors | 2 |
USB 3.2 Gen 2 (3.1 Gen 2) connectors | 1 |
BIOS Type | UEFI AMI |
Package width | 275 mm |
Package depth | 275 mm |
Package height | 67.5 mm |
PACKAGE WEIGHT | 1.68 kg |
Antenna included | Yes |
CABLES INCLUDED | SATA |
Screws included | Yes |
RAID levels | 1 |
Supported storage drive types | HDD & SSD |
Number of storage drives supported | 7 |
Raid Support | Yes |
Supported storage drive interfaces | M.2, SATA III |
Number of HDDs supported | 4 |
USB 3.2 Gen 2x2 Type-C ports quantity | 1 |
Ethernet LAN (RJ-45) ports | 1 |
USB 2.0 ports quantity | 4 |
WiFi-AP antenna jack | 1 |
USB 3.2 Gen 1 (3.1 Gen 1) Type-A ports quantity | 4 |
USB 3.2 Gen 2 (3.1 Gen 2) Type-A ports quantity | 3 |
DisplayPorts quantity | 1 |
HDMI ports quantity | 1 |
PCI Express x16 (Gen 5.x) slots | 1 |
PCI Express x1 (Gen 4.x) slots | 1 |
2nd M.2 largest key size | 2280 |
3rd M.2 highest PCI Express generation | 4.0 |
1st M.2 largest key size | 2280 |
3rd M.2 largest key size | 2280 |
2nd M.2 highest PCI Express generation | 4.0 |
1st M.2 highest PCI Express generation | 5.0 |
Number of M.2 (M) slots | 3 |
PCI Express x16 (Gen 4.x) slots | 1 |
Weight | 1.2 kg |
Warnings | Do not disassemble to avoid damage to internal components and loss of warranty. |
