Compatible processor series | AMD Ryzen™ 9000 Series |
Processor Socket | Socket AM5 |
Processor manufacturer | AMD |
Maximum number of SMP processors | 1 |
Audio output channels | 7.1 channels |
MOTHERBOARD CHIPSET | AMD X870 |
audio chip | Realtek ALC4080 |
Motherboard form factor | ATX |
Motherboard chipset family | AMD |
Windows operating systems supported | Windows 10 x64 |
Operating system architecture | 64-bit |
Unbuffered memory | Yes |
Maximum internal memory | 256 GB |
Number of memory slots | 4 |
Supported memory clock speed (max) | 8000+ MHz |
Memory channels | Dual-channel |
Supported memory types | DDR5-SDRAM |
Memory slots type | DIMM |
Depth | 244 mm |
Width | 305 mm |
Bluetooth Version | 5.4 |
Bluetooth | Yes |
Ethernet LAN | Yes |
LAN controller | Killer E3100 |
Wi-Fi | Yes |
Ethernet interface type | 2.5 Gigabit Ethernet |
Top Wi-Fi standard | Wi-Fi 7 (802.11be) |
Wi-Fi standards | Wi-Fi 4 (802.11n) |
USB 2.0 connectors | 4 |
RGB LED pin header | Yes |
Front panel audio connector | Yes |
USB 3.2 Gen 2 (3.1 Gen 2) connectors | 1 |
USB 3.2 Gen 1 (3.1 Gen 1) connectors | 2 |
CPU fan connector | Yes |
ATX Power connector (24-pin) | Yes |
Number of SATA III connectors | 4 |
BIOS Type | UEFI AMI |
Supported storage drive interfaces | Blazing M.2 (PCIe Gen5 x4), Hyper M.2 (PCIe Gen4 x4) |
Wi-Fi antenna socket | Yes |
Line-out | Yes |
USB 3.2 Gen 2 (3.1 Gen 2) Type-A ports quantity | 2 |
S/PDIF out port | Yes |
Ethernet LAN (RJ-45) ports | 1 |
HDMI ports quantity | 1 |
USB 3.2 Gen 1 (3.1 Gen 1) Type-A ports quantity | 3 |
Microphone in | Yes |
USB 3.2 Gen 2x2 Type-C ports quantity | 2 |
PCI Express x16 (Gen 5.x) slots | 1 |
