Processor Socket | Socket AM4 |
Maximum number of SMP processors | 1 |
Compatible processor series | 3rd Generation AMD Ryzen™ 9 |
Processor manufacturer | AMD |
Maximum graphics card memory | 16000 MB |
Maximum Resolution | 4096 x 2160 pixels |
Parallel processing technology support | 2-Way CrossFireX |
Number of mounting holes | 9 |
Harmonized System (HS) code | 84733020 |
Audio output channels | 7.1 channels |
audio chip | Realtek ALC892 |
MOTHERBOARD CHIPSET | AMD B550 |
Motherboard form factor | ATX |
PC health monitoring | Fan |
Motherboard chipset family | AMD |
Memory slots type | DIMM |
Memory channels | Dual-channel |
Supported memory types | DDR4-SDRAM |
Number of memory slots | 4 |
Supported memory clock speeds | 1866 |
Unbuffered memory | Yes |
Maximum internal memory | 128 GB |
Depth | 244 mm |
Width | 305 mm |
Height | 65 mm |
Ethernet interface type | Gigabit Ethernet |
Ethernet LAN | Yes |
Wi-Fi | No |
LAN controller | Realtek 8111H |
TPM connector | Yes |
RGB LED pin header | Yes |
12V power connector | Yes |
Number of SATA III connectors | 6 |
USB 2.0 connectors | 2 |
Front panel audio connector | Yes |
Chassis intrusion connector | Yes |
CPU fan connector | Yes |
Number of chassis fan connectors | 6 |
ATX Power connector (24-pin) | Yes |
USB 3.2 Gen 1 (3.1 Gen 1) connectors | 1 |
Clear CMOS jumper | Yes |
BIOS Type | UEFI AMI |
Drivers included | Yes |
CABLES INCLUDED | SATA |
Supported storage drive types | HDD & SSD |
Supported storage drive interfaces | SATA III |
RAID levels | 10 |
USB 3.2 Gen 2 (3.1 Gen 2) Type-A ports quantity | 1 |
HDMI ports quantity | 1 |
PS/2 ports quantity | 1 |
USB 3.2 Gen 1 (3.1 Gen 1) Type-A ports quantity | 2 |
USB 3.2 Gen 2 (3.1 Gen 2) Type-C ports quantity | 1 |
S/PDIF out port | Yes |
Ethernet LAN (RJ-45) ports | 1 |
Digital audio optical out | 1 |
DisplayPorts quantity | 1 |
USB 2.0 ports quantity | 4 |
PCI Express x16 (Gen 4.x) slots | 1 |
Number of M.2 (M) slots | 2 |
PCI Express x1 (Gen 3.x) slots | 2 |
PCI Express x16 (Gen 3.x) slots | 1 |
Weight | 1 kg |
