energy | |
overall performance | 700 W |
AC input voltage | 230 V |
AC input frequency | 50 - 60 Hz |
input current | 3 A |
Power Factor Correction Filter (PFC) | Aktiv |
Combined Current (+3.3V) | 150 W |
Combined power (+12V) | 540 W |
Combined current (+5V) | 150 W |
Combined current (-12V) | 9,6 W |
Combined current (+5Vsb) | 12,5 W |
Max. output current (+3.3V) | 18 A |
Max. output current (+12V1) | 24 A |
Max output current (+12V2) | 24 A |
Max output current (+5V) | 18 A |
Max. output current (-12V) | 0,8 A |
Max. output current (+5Vsb) | 2,5 A |
efficiency | 82% |
connections and interfaces | |
Motherboard connector plug | 20+4 pin ATX |
Number of SATA power plugs | 4 |
Number of Molex connectors 4pin | 3 |
Number of PCI Express power connectors 6+2pin | 2 |
Eigenschaft | Garantiekarte |
Floppy drive power connection | 1 |
cable type | Nicht-modular |
Services | |
purpose | PC |
Power supply unit (PSU) form factor | ATX |
ATX-Version | 2.4 |
noise level | 25 dB |
Design | |
Product color | Silber |
cooling | Aktiv |
fan diameter | 12 cm |
number of fans | 1 Lüfter |
weight and dimensions | |
broad | 150 mm |
depth | 140 mm |
height | 86 mm |
Weight | 1,07 kg |
package weight | 1,36 kg |
packaging type | Box |
logistic data | |
Goods tariff number (HS) | 84733020 |
Other functions | |
