energy | |
overall performance | 850 W |
AC input voltage | 100 - 240 V |
AC input frequency | 47 - 63 Hz |
input current | 10 - 5 A |
Combined Current (+3.3V) | 150 W |
Combined power (+12V) | 849,6 W |
Combined current (+5V) | 150 W |
Combined current (+5Vsb) | 15 W |
Max. output current (+3.3V) | 20 A |
Max. output current (+12V) | 70,8 A |
Max output current (+5V) | 20 A |
Max. output current (+5Vsb) | 3 A |
efficiency | 90% |
energy conservation properties | Überstrom, Überlastung, Überspannung, Überhitzung, Kurzschluß |
connections and interfaces | |
Motherboard connector plug | 24-pin ATX |
Power cable length motherboard | 61 cm |
Number of SATA power plugs | 12 |
SATA power cable length | 455,570,685,800 mm |
Number of Molex connectors 4pin | 2 |
Peripheral (Molex) power cord length | 450,550,650,750 mm |
Eigenschaft | Kabelbinder enthalten |
Number of PCI Express power connectors 6+2pin | 3 |
PCI Express power connectors (16-pin) | 1 |
PCI Express power cord length | 75 cm |
cable type | Vollständig modular |
Services | |
80 plus certification | 80 PLUS Gold |
purpose | PC / Server |
Power supply unit (PSU) form factor | ATX |
ATX-Version | 3.0 |
EPS-Version | 2.92 |
Design | |
Product color | Schwarz |
cooling | Aktiv |
fan diameter | 14 cm |
number of fans | 1 Lüfter |
scope of delivery | |
Supplied cables | AC, Gleichstrom |
weight and dimensions | |
broad | 150 mm |
depth | 160 mm |
height | 86 mm |
Weight | 3,28 kg |
Technical details | |
Konformitätsbescheinigungen | Niederspannungsrichtlinie (LVD), RoHS, UKCA |
