Sustainability certificates | ErP |
Fan location | Top |
Product colour | Black |
Fan Diameter | 12 cm |
On/off switch | Yes |
Number of fans | 1 fan(s) |
Cooling type | Active |
Combined power (+5V) | 100 W |
Power protection features | Over power |
Total power | 750 W |
Max output current (-12V) | 0.3 A |
Hold time | 16 ms |
AC input frequency | 50/60 Hz |
Combined power (+12V) | 750 W |
Max output current (+3.3V) | 20 A |
Combined power (+5Vsb) | 15 W |
Combined power (+3.3V) | 100 W |
AC input voltage | 100 - 240 V |
Efficiency | 90% |
Power Good signal delay range | 100 - 150 ms |
Max output current (+5V) | 20 A |
Max output current (+12V) | 62.5 A |
Power Factor Correction (PFC) type | Active |
Input current | 10 - 5 A |
Combined power (-12V) | 3.6 W |
Max output current (+5Vsb) | 3 A |
Operating temperature (T-T) | 0 - 50 °C |
Weight | 2.62 kg |
Height | 86 mm |
Depth | 160 mm |
Width | 150 mm |
Certification | TUV, CE, CCC, EAC, RCM, cTUVus, FCC, BSMI, BIS,
UKCA |
Mean time between failures (MTBF) | 100000 h |
Purpose | PC |
ATX version | 3.1 |
80 PLUS Certification | 80 PLUS Gold |
Power supply unit (PSU) form factor | ATX |
Bearing technology | HDB |
Package depth | 310 mm |
PACKAGE WEIGHT | 2.9 kg |
Package height | 120 mm |
Package Type | Box |
Package width | 194 mm |
SATA power cable length | 500 mm |
Cabling Type | Fully-Modular |
EPS power connector (4+4 pin) | Yes |
ATX Power connector (24-pin) | Yes |
Motherboard power connector | 24-pin ATX |
EPS power connector (8-pin) | Yes |
Motherboard power cable length | 61 cm |
Peripheral (Molex) power cable length | 740 |
Number of SATA power connectors | 12 |
PCI Express power connectors (6+2 pin) | 4 |
Peripheral (Molex) power connectors (4-pin) | 4 |
Warnings | Do not open the case - risk of electric shock. |
