energy | |
overall performance | 500 W |
AC input voltage | 100 - 240 V |
AC input frequency | 50 - 60 Hz |
input current | 8-4 A |
Power Factor Correction Filter (PFC) | Aktiv |
Combined Current (+3.3V) | 90 W |
Combined current (+5V) | 90 W |
Max. output current (+3.3V) | 14 A |
Max. output current (+12V) | 41 A |
Max output current (+5V) | 16 A |
Max. output current (-12V) | 0,3 A |
Max. output current (+5Vsb) | 3 A |
efficiency | 90% |
energy conservation properties | Überstrom, Überlastung, Überspannung, Überhitzung, Kurzschluß |
connections and interfaces | |
Motherboard connector plug | 24-pin ATX |
Number of SATA power plugs | 4 |
Number of Molex connectors 4pin | 2 |
Eigenschaft | Diskettenlaufwerkstecker |
Number of PCI Express power connectors 6+2pin | 2 |
Floppy drive power connection | 1 |
cable type | Nicht-modular |
Services | |
80 plus certification | 80 PLUS Gold |
purpose | NAS/Speicherserver |
Power supply unit (PSU) form factor | 1U |
storage type | Kugellager |
Design | |
Product color | Schwarz |
cooling | Aktiv |
fan diameter | 4 cm |
number of fans | 1 Lüfter |
scope of delivery | |
Supplied cables | CPU, PCIe, Peripheral (Molex), SATA |
weight and dimensions | |
broad | 40,5 mm |
depth | 150 mm |
height | 81,5 mm |
