Warranty period | 10 year(s) |
Fan Diameter | 12 cm |
Product colour | White |
Cooling type | Active |
Number of fans | 1 fan(s) |
On/off switch | Yes |
Fan location | Top |
Max output current (+5Vsb) | 3 A |
Power protection features | Short circuit |
Hold time | 16 ms |
Combined power (+12V) | 849.6 W |
Combined power (+5V) | 125 W |
Max output current (+3.3V) | 25 A |
Combined power (-12V) | 3.6 W |
AC input voltage | 100 - 240 V |
Input current | 12 A |
Combined power (+5Vsb) | 15 W |
Max output current (+5V) | 25 A |
AC input frequency | 50/60 Hz |
Max output current (-12V) | 0.3 A |
Power Factor Correction (PFC) type | Active |
Combined power (+3.3V) | 125 W |
Max output current (+12V) | 70.8 A |
Efficiency | 90% |
Power Good signal delay range | 100 - 150 ms |
Total power | 850 W |
Height | 86 mm |
Width | 150 mm |
Depth | 140 mm |
Weight | 2.68 kg |
Power supply unit (PSU) form factor | ATX |
ATX version | 3.1 |
Mean time between failures (MTBF) | 100000 h |
80 PLUS Certification | 80 PLUS Platinum |
Bearing technology | Ball bearing |
Purpose | PC |
Package depth | 206 mm |
Package width | 340 mm |
PACKAGE WEIGHT | 3.31 kg |
Package height | 120 mm |
Package Type | Box |
Peripheral (Molex) power connectors (4-pin) | 4 |
PCI Express power connectors (6+2 pin) | 6 |
Number of SATA power connectors | 8 |
Floppy disk drive connector | Yes |
PCI Express connector | Yes |
Floppy drive power connector | 2 |
Cabling Type | Fully-Modular |
Motherboard power connector | 20+4 pin ATX |
ATX power connector (20+4 pin) | Yes |
CPU power connector (4+4 pin) | Yes |
Motherboard power cable length | 65 cm |
