Sustainability certificates | RoHS |
Warranty period | 5 year(s) |
Compliance certificates | CCC |
Product colour | Black |
Fan Diameter | 12 cm |
Cooling type | Active |
Illumination | No |
Fan location | Top |
Number of fans | 1 fan(s) |
Maximum input current (@220V) | 12 A |
AC input voltage | 100 - 240 V |
Combined power (+5V) | 105 W |
Power Factor Correction (PFC) type | Active |
Max output current (+5V) | 20 A |
Power protection features | Short circuit |
Combined power (+5Vsb) | 15 W |
AC input frequency | 50 - 60 Hz |
Efficiency | 90% |
Max output current (+3.3V) | 20 A |
Input current | 12 - 6 A |
Combined power (-12V) | 3.6 W |
Max output current (+12V) | 70.8 A |
Combined power (+3.3V) | 105 W |
Hold time | 16 ms |
Max output current (+5Vsb) | 3 A |
Maximum input current (@110V) | 6 A |
Total power | 850 W |
Combined power (+12V) | 850 W |
Max output current (-12V) | 0.3 A |
Width | 150 mm |
Depth | 140 mm |
Height | 85 mm |
Mean time between failures (MTBF) | 100000 h |
80 PLUS Certification | 80 PLUS Gold |
Power supply unit (PSU) form factor | ATX |
Purpose | PC |
Noise level | 40 dB |
Package Type | Box |
Cable tie(s) included | Yes |
CABLES INCLUDED | CPU, PATA, Peripheral (Molex), SATA |
PCI Express connector | Yes |
Peripheral (Molex) power cable length | 200 |
PCI Express power connectors (16-pin) | 1 |
Peripheral (Molex) power connectors (4-pin) | 2 |
Motherboard power cable length | 61 cm |
Motherboard power connector | 20+4 pin ATX |
Cabling Type | Fully-Modular |
ATX power connector (20+4 pin) | Yes |
PCI Express power connectors (6+2 pin) | 4 |
Number of SATA power connectors | 8 |
Number of PATA power connectors | 3 |
SATA power cable length | 150 |
CPU power connector (4+4 pin) | Yes |
PCI Express power cable length | 70 cm |
