Sustainability certificates | RoHS |
On/off switch | Yes |
Product colour | Black |
Cooling type | Active |
Max output current (+5Vsb) | 3 A |
Max output current (-12V) | 0.3 A |
Total power | 750 W |
Power protection features | Under voltage |
Combined power (+5Vsb) | 15 W |
Combined power (+3.3V) | 100 W |
Max output current (+12V) | 62 A |
Combined power (+12V) | 744 W |
Max output current (+5V) | 20 A |
Max output current (+3.3V) | 20 A |
Input current | 5 - 10 A |
AC input frequency | 50 - 60 Hz |
AC input voltage | 100 - 240 V |
Combined power (-12V) | 3.6 W |
Combined power (+5V) | 100 W |
Operating temperature (T-T) | 0 - 50 °C |
Operating relative humidity (H-H) | 15 - 65% |
Height | 86 mm |
Width | 150 mm |
Depth | 140 mm |
Certification | cTUVus, TUV, CB, CCC, BSMI, EAC, CE, WEEE, ErP Lot 6, REACH |
Purpose | PC |
Mean time between failures (MTBF) | 150000 h |
Supported motherboard form factors | ATX |
80 PLUS Certification | 80 PLUS Gold |
Power supply unit (PSU) form factor | ATX |
Bearing technology | FDB |
Manual | Yes |
Package Type | Box |
CABLES INCLUDED | CPU, PCIe, Peripheral (Molex), Peripheral (Molex) to SATA 3.3, SATA |
PCI Express power cable length | 28 cm |
PCI Express power connectors (8-pin) | 4 |
Peripheral (Molex) power cable length | 690 mm |
Number of SATA power connectors | 3 |
CPU power connectors (8-pin) | 2 |
SATA power cable length | 230 |
Motherboard power connector | 20+4 pin ATX |
Motherboard power cable length | 20 cm |
CPU power cable length | 23 cm |
Cabling Type | Fully-Modular |
Peripheral (Molex) power connectors (4-pin) | 1 |
Screws included | Yes |
Number of screws | 4 |
Harmonized System (HS) code | 84733020 |
