Promag PCR300 are desktop rfid readers which can be used for system logon/logoff, operator identification and many other desktop rfid applications.

PCR300 readers are available in several versions depending which card technology, casing and output you require:

Card Technology:
13.56MHz MIFARE (PCR300M)
125Khz RFID (PCR300A

Case Types: Cradle slot or flat casing

Output: Decimal or Hexadecimal

Cradle slot is designed to accept RFID card as below:
System Unlocked - System can be used when the registered card is sitting in the cradle slot
System Locked - System cannot be used when the registered card is removed from the cradle slot.

Specifications

• Power requirements: 5 V / 200 mA
• Interface: USB (Virtual COM) or RS232
• Supported Card Types:
  13.56MHz MIFARE (PCR330M)
  125kHz RFID (PCR330A)
• Dimension (mm): W 65 X L 100 X D23 mm
• Card dimension: 86 x 55 x 2 mm maximum

Available Versions
