management functions | |
Eigenschaft | Rackmontageset |
connections and interfaces | |
Number of basic switching RJ-45 Ethernet ports | 10 |
Basic Switching RJ-45 Ethernet Ports-Typ | Gigabit Ethernet (10/100/1000) |
Number of installed SFP modules | 2 |
USB 3.2 Gen 1 (3.1 Gen 1) Number of Type A ports | 1 |
Compatible memory cards | MicroSD (TransFlash) |
network | |
mesh standard | IEEE 802.1Q, IEEE 802.1p, IEEE 802.1x, IEEE 802.3, IEEE 802.3af, IEEE 802.3at, IEEE 802.3u, IEEE 802.3x |
data transmission | |
throughput | 1 Gbit/s |
safety | |
Supported security algorithms | SNMP, SSH |
logs | |
Supported network protocols | IPv4, IPv6, IEEE802.1q ,IEEE 802.1p, IEEE802.1x, IEEE802.3, IEEE 802.3u, IEEE 802.3x,IEEE802.3ab |
Design | |
Product color | Schwarz, Silber |
housing material | Metall |
LED indicators | PoE, Status |
Services | |
storage capacity | 2048 MB |
Flash memory | 32768 MB |
energy | |
energy source | DC/PoE |
AC input voltage | 100 - 240 V |
AC input frequency | 50/60 Hz |
Power Over Ethernet (PoE) | |
Number of Power over Ethernet (PoE) ports | 4 |
Overall Power over Ethernet (PoE) | 36 W |
operating conditions | |
operating temperatur | 0 - 45 °C |
Storage temperature range | -30 - 60 °C |
Operating relative humidity | 5 - 95% |
weight and dimensions | |
broad | 280 mm |
depth | 180 mm |
height | 44 mm |
Weight | 1,2 kg |
scope of delivery | |
package weight | 1,6 kg |
certificates | |
certification | FCC, CE, RCM, IC |
