| management functions | |
| Eigenschaft | Rackmontageset |
| connections and interfaces | |
| Number of basic switching RJ-45 Ethernet ports | 10 |
| Basic Switching RJ-45 Ethernet Ports-Typ | Gigabit Ethernet (10/100/1000) |
| Number of installed SFP modules | 2 |
| USB 3.2 Gen 1 (3.1 Gen 1) Number of Type A ports | 1 |
| Compatible memory cards | MicroSD (TransFlash) |
| network | |
| mesh standard | IEEE 802.1Q, IEEE 802.1p, IEEE 802.1x, IEEE 802.3, IEEE 802.3af, IEEE 802.3at, IEEE 802.3u, IEEE 802.3x |
| data transmission | |
| throughput | 1 Gbit/s |
| safety | |
| Supported security algorithms | SNMP, SSH |
| logs | |
| Supported network protocols | IPv4, IPv6, IEEE802.1q ,IEEE 802.1p, IEEE802.1x, IEEE802.3, IEEE 802.3u, IEEE 802.3x,IEEE802.3ab |
| Design | |
| Product color | Schwarz, Silber |
| housing material | Metall |
| LED indicators | PoE, Status |
| Services | |
| storage capacity | 2048 MB |
| Flash memory | 32768 MB |
| energy | |
| energy source | DC/PoE |
| AC input voltage | 100 - 240 V |
| AC input frequency | 50/60 Hz |
| Power Over Ethernet (PoE) | |
| Number of Power over Ethernet (PoE) ports | 4 |
| Overall Power over Ethernet (PoE) | 36 W |
| operating conditions | |
| operating temperatur | 0 - 45 °C |
| Storage temperature range | -30 - 60 °C |
| Operating relative humidity | 5 - 95% |
| weight and dimensions | |
| broad | 280 mm |
| depth | 180 mm |
| height | 44 mm |
| Weight | 1,2 kg |
| scope of delivery | |
| package weight | 1,6 kg |
| certificates | |
| certification | FCC, CE, RCM, IC |
