Design | |
product type | IP-Telefon |
Hearing type | Kabelgebundenes Mobilteil |
Product color | Schwarz |
Eigenschaft | Betriebsanleitung |
Assembly | Tisch/Wand |
Services | |
Installed operating system | Linux |
Dual-Tone-Multifrequenz-Modi (DTMF) | Im Band, Außerhalb des Bandes, SIP-Info |
phone properties | |
line count | 12 Zeilen |
phone book capacity | 1000 Eintragungen |
management functions | |
volume control | Tasten |
Keyboard Number of keys | 12 |
Number of programmable keys | 12 |
number of function keys | 9 |
screen | |
Display | TFT |
screen size | 10,9 cm (4.3") |
Display resolution | 480 x 272 Pixel |
Audio | |
voice codec | G.711Mu, G.711a, G.722, G.726, G.729ab, GSM 6.10 |
network | |
Interface type Ethernet LAN | Gigabit Ethernet |
Ethernet LAN data transfer rates | 10,100,1000 Mbit/s |
Supported network protocols | DHCP, HTTP, NTP, LDAP, TFTP, HTTPS |
mesh standard | IEEE 802.1Q, IEEE 802.1x, IEEE 802.3, IEEE 802.3af |
connections and interfaces | |
Number of USB 2.0 ports | 1 |
Number of Ethernet LAN ports (RJ-45) | 2 |
Number of RJ9 ports | 2 |
energy | |
Power pack input voltage | 100 - 240 V |
input frequency | 50/60 Hz |
power supply output voltage | 5 V |
AC adapter output current | 2 A |
Power consumption (standard operation) | 10 W |
operating conditions | |
operating temperatur | 0 - 35 °C |
Operating relative humidity | 5 - 95% |
humidity during storage | 5 - 95% |
Storage temperature range | -10 - 45 °C |
weight and dimensions | |
broad | 250 mm |
depth | 185 mm |
height | 120 mm |
Weight | 880 g |
scope of delivery | |
Number of handles included | 1 Stück(e) |
Supplied cables | LAN (RJ-45) |
