Design | |
Product color | Weiß |
housing material | Metall, Polycarbonat (PC) |
Assembly | Wandmontage |
market positioning | Business |
Eigenschaft | Web-basiertes Management |
LED indicators | Netzwerk, Status |
Ethernet LAN characteristics | |
Interface type Ethernet LAN | Gigabit Ethernet |
Ethernet LAN data transfer rates | 10,100,1000 Mbit/s |
mesh standard | IEEE 802.11a, IEEE 802.11ac, IEEE 802.11b, IEEE 802.11g, IEEE 802.11n, IEEE 802.3af |
Supported network protocols | IPv4/IPv6, PPP, PPPoE, SNMP v1/v2c/v3, TCP, UDP, DHCP, RIPv1/v2, OSPF, DDNS, VRRP, HTTP, HTTPS, DNS, ARP, QOS, SNTP, Telnet, VLAN, SSH |
Wireless LAN functions | |
WLAN-Standards | 802.11a, 802.11b, 802.11g, Wi-Fi 4 (802.11n), Wi-Fi 5 (802.11ac) |
Data transfer speed WiFi | 1733 Mbit/s |
mobile network | |
data network | 4G, 5G, LTE |
4G-Standards | LTE |
Number of SIM cards | 1 |
SIM card type | MiniSIM |
connections and interfaces | |
Number of Ethernet LAN ports (RJ-45) | 2 |
serial interface | |
Serial interface | RS-232/485 |
Number of serial ports | 1 |
Baudrate | 230400 Kbit/s |
safety | |
Supported security algorithms | AES, TKIP, WEP, WPA, WPA2 |
VPN support | DMVPN, IPsec, OpenVPN, PPTP, L2TP, GRE |
Services | |
processor manufacturer | Qualcomm |
processor clock speed | 716,8 GHz |
RAM capacity | 0,512 GB |
RAM type | DDR3 |
certification | CE, FCC, RoHS |
management functions | |
management logs | CLI, SMS, On-demand dial up, SNMP v1/v2/v3, DeviceHub |
Antenna | |
antenna type | Intern |
number of antennas | 8 |
energy | |
energy source | Gleichstrom, PoE |
output voltage | 9 - 48 V |
operating conditions | |
operating temperatur | -40 - 70 °C |
Storage temperature range | -40 - 85 °C |
Operating relative humidity | 0 - 95% |
weight and dimensions | |
broad | 105 mm |
depth | 110 mm |
height | 218 mm |
