Design | |
Product color | Weiß |
LED indicators | System |
International degree of protection (IP code) | IP67 |
Services | |
Eigenschaft | Nachhaltigkeitskonformität |
processor clock speed | 1500 MHz |
storage capacity | 512 MB |
Internal storage type | DDR4 |
Flash memory | 8192 MB |
logs | |
Supported network protocols | PPPoE, SNMP v1/v2c/v3, TCP, UDP, DHCP, DDNS, HTTP, HTTPS, DNS, ARP, SNTP, Telnet, SSH, MQTT, BACnet/IP |
network | |
Ethernet LAN data transfer rates | 10,100,1000 Mbit/s |
mesh standard | IEEE 802.11b, IEEE 802.11g, IEEE 802.11n |
frequency band | 2.4 GHz |
VPN support | OpenVPN/IPsec/PPTP/L2TP/GRE/DMVPN ACL/DMZ/Allocation of |
safety | |
Supported security algorithms | AES, TKIP, WEP, WPA, WPA2 |
connections and interfaces | |
Number of Ethernet LAN ports (RJ-45) | 1 |
management functions | |
energy | |
Power consumption (standard operation) | 3,6 W |
Power consumption (max.) | 4,8 W |
DC input voltage | 12 V |
weight and dimensions | |
broad | 164 mm |
depth | 90,9 mm |
height | 240 mm |
operating conditions | |
operating temperatur | -40 - 70 °C |
Storage temperature range | -40 - 85 °C |
Operating relative humidity | 0 - 95% |
sustainability | |
certificates | |
Konformitätsbescheinigungen | CE, Eidgenössische Kommunikationskommission (FCC), RoHS |
