To press | |
Maximum resolution | 180 x 180 DPI |
Print speed (metric) | 500 mm/sek |
Zeichengröße | 1,41 x 3,39 mm |
Zeichen | Text, Grafik, Barcode, 2D-Strichcode |
Character Map | ANK |
printing technology | |
Type | POS-Drucker |
paper handling | |
Print Media - Thickness | 48 - 80 µm |
Maximum roll diameter | 8,3 cm |
Supported paper width | 80 mm |
media strength | 48 - 80 mm |
connections and interfaces | |
Eigenschaft | Austauschbare Schnittstelle |
USB connector type | USB Type-A / USB Type-B |
Serial interface | RS-232 |
transmission technology | Verkabelt & Kabellos |
Optional connectivity | Wireless LAN |
network | |
features | |
Sound pressure level (pressure) | 52 dB |
Sound pressure level (standby) | 52 dB |
Mean Time Between Failures (MTBF) | 360000 h |
Car cutter durability | 3 Millionen Schnitte |
Lebensdauer des Druckkopfes | 200 km |
Country of origin | Philippinen |
Montageposition | Horizontal/Vertikal |
Details der eingebauten Sensoren | Paper End Sensor, Paper Near End Sensor, Cover Open Sensor, Receipt paper sensor |
certification | CE |
Design | |
Product color | Schwarz |
energy | |
Average power consumption when printing | 27,9 W |
AC input voltage | 24 V |
power consumption | 27900 mA |
Power consumption (standby) | 1,4 W |
operating conditions | |
operating temperatur | 5 - 45 °C |
Storage temperature range | -10 - 50 °C |
Operating relative humidity | 10 - 90% |
humidity during storage | 10 - 90% |
system requirement | |
preinstalled software | Server Direct Print, ePOS-Device, ePOS-Display, ePOS-Print |
weight and dimensions | |
broad | 145 mm |
depth | 195 mm |
height | 148 mm |
Weight | 1,7 kg |
quantity per pack | 1 Stück(e) |
package weight | 2,7 kg |
Teilenkapazität | 42/56 |
logistic data | |
Palettengewicht (UK) | 0 g |
Goods tariff number (HS) | 84433210 |
products per pallet | 112 Stück(e) |
Pallet weight (gross) | 0 g |
Technical details | |
Lebenszeit | 20000000 lines |
Other functions | |
buffer size | 4 KB |
Mittelzyklen zwischen Fehler (MCBF) | 70000000 |
