The ZyXEL GS1900 Series is equipped with advanced management features to make the network stable and secure: loop protection that prevents network flooding, dual images to provide a backup FW if one crashes and storm control to ensure network efficiency, friendly on/off DoS with simple click to enable/disable instead of several setup pages, while SSL ensures the management frames are well encrypted when the device is accessed. The GS1900 Series provides network error prevention features and integrated network security for reduced risk and improved data streaming.
Kaal, g | 720 |
Portide arv | 10 |
Mõõtmed W x D x H, mm | 250 x 104 x 27 |
Sertifitseerimine | CE, FCC, C-Tick, Class B, BSMI CNS13438 |
Ethernet LAN (RJ-45) PoE portide arv | 8 |
Automaatne MDI/MDI-X | Yes |
Teenusekvaliteedi (QoS) tugi | Yes |
Turvalisuse algoritmide tugi | RADIUS, TACACS+ |
Lülitusvõimsus, Gbit/s | 16 |
IGMP nuhkimine | Yes |
Vaheta kihti | L2 |
Edastage tormikontroll | Yes |
Võrgustiku standardid | IEEE 802.3, IEEE 802.3u, IEEE 802.3ab, IEEE 802.3x, IEEE 802.3az, IEEE 802.1p, IEEE 802.3af, IEEE 802.3at |
Jumbo Frames tugi | Yes |
Jaoturi tüü | Managed |
Power over Ethernet (PoE) tugi | Yes |
Pakettide edastamise kiirus | 11.9 Mpps |
Lühike kirjeldus (kokkuvõte) | The ZyXEL GS1900 Series is equipped with advanced management features to make the network stable and secure: loop protection that prevents network flooding, dual images to provide a backup FW if one crashes and storm control to ensure network efficiency, friendly on/off DoS with simple click to enable/disable instead of several setup pages, while SSL ensures the management frames are well encrypted when the device is accessed. The GS1900 Series provides network error prevention features and integrated network security for reduced risk and improved data streaming. |
MAC-aadresside tabel, kirjed | 8000 |
Energiatarbimine, W | 90 |
SSH/SSL tugi | Yes |
Maksimaalne andmeedastuskiirus, Gbit/s | 1 |
Toote värv | Black |
MIB tugi | RFC 1213, RFC 2819, RFC 1215, RFC 1493 |
SFP slots quantity | 2 |
MAC-aadressi filtreerimine | Yes |
Haldusprotokollid | SNMP v1, v2, v3, RMON (1, 2, 3, 9) |
Ohutus | LVD EN60950-1, BSMI CNS14336-1 |
Kohtvõrgukaardi tüüp | 10/100/1000 Base-T(X) |
