Services | |
Type | IP-Sicherheitskamera |
Unterstützte Positionierung | Innen & Außen |
transmission technology | Kabelgebunden |
Eigenschaft | IP-Adressen Filter |
Design | |
form factor | Glühbirne |
attachment type | Decke/Wand |
Product color | Schwarz, Weiß |
International degree of protection (IP code) | IP66, IP67 |
IK-Kodex | IK10 |
Camera | |
rotation angle | 170° |
viewing angle (horizontal) | 107 - 39° |
viewing angle (vertical) | 55 - 22° |
Lens viewing angle, diagonal | 131 - 45° |
tilt angle range | -75 - 75° |
swivel range | -100 - 110° |
camera shutter speed | 1/20000 - 1.5 s |
image sensor | |
Image sensor size | 25,4 / 2,8 mm (1 / 2.8") |
Sensor-Typ | CMOS |
Panoramakamera | |
Sensortyp (Panoramakamera) | CMOS |
Größe des optischen Sensors (Panoramakamera) | 25,4 / 2,8 mm (1 / 2.8") |
Verschlusszeit der Kamera (Panoramakamera) | 1/20000 - 1.5 s |
Mindestbeleuchtung (Panoramakamera) | 0,1 Lux |
lens | |
number of lenses | 1 |
focal range | 3.3 – 8.1 |
night vision | |
LED Type | IR |
Video | |
Maximum resolution | 1920 x 1080 Pixel |
total megapixels | 2 MP |
Video compression formats | H.264, H.265, M-JPEG |
Supported graphic resolutions | 640 x 360, 1920 x 1080 (HD 1080) |
Supported video modes | 1080p |
Up to 30 frames per second | 60 fps |
image quality adjustment | Helligkeit, Kontrast, Schärfe |
Audio | |
Audio-System | 2-Wege |
network | |
Ethernet interfaces type | Gigabit Ethernet |
mesh standard | IEEE 802.1x, IEEE 802.3at |
storage medium | |
connections and interfaces | |
Number of Ethernet LAN ports (RJ-45) | 1 |
safety | |
Supported security algorithms | HTTPS |
energy | |
energy source | PoE |
Power Consumption (Power over Ethernet (PoE)) | 7,9 W |
operating conditions | |
operating temperatur | -30 - 50 °C |
Storage temperature range | -40 - 65 °C |
Operating relative humidity | 5 - 95% |
weight and dimensions | |
broad | 133 mm |
depth | 208 mm |
height | 88 mm |
Weight | 975 g |
scope of delivery | |
number of cameras | 2 |
Technical details | |
Does not contain | BFR, PVC |
