| Services | |
| Type | IP-Sicherheitskamera |
| Unterstützte Positionierung | Innen & Außen |
| transmission technology | Kabelgebunden |
| Eigenschaft | Montageset |
| certification | UL/cUL, UKCA, CE, KC, EAC, RCM, TAA |
| Design | |
| form factor | Dome |
| attachment type | Zimmerdecke |
| Product color | Schwarz, Weiß |
| housing material | Aluminium, Polycarbonat (PC) |
| International degree of protection (IP code) | IP66 |
| IK-Kodex | IK10 |
| Camera | |
| minimum lighting | 0,01 Lux |
| viewing angle (horizontal) | 77 - 3.6° |
| viewing angle (vertical) | 43.1 - 2° |
| tilt angle range | 0 - 180° |
| incline speed | 350 °/Sekunde |
| swivel range | 0 - 360° |
| Webcam - Pan speed | 350 °/Sekunde |
| camera shutter speed | 1/66500 - 2 s |
| image sensor | |
| number of sensors | 1 |
| Image sensor size | 25,4 / 2,8 mm (1 / 2.8") |
| Sensor-Typ | CMOS |
| lens | |
| Optical zoom | 21x |
| digital zoom | 12x |
| number of lenses | 1 |
| focal range | 4 - 84.6 mm |
| Maximum f-number | 4,5 |
| Minimum f-number | 1,6 |
| Abstandsfeststellung (wide) | 57 m |
| Abstandsfeststellung (tele) | 1120 m |
| Abstandsbeobachtung (wide) | 23 m |
| Abstandsbeobachtung (tele) | 450 m |
| Abstandserkennung (wide) | 11 m |
| Abstandserkennung (tele) | 225 m |
| Abstandsermittlung (wide) | 6 m |
| Abstandsermittlung (tele) | 110 m |
| Video | |
| Maximum resolution | 1920 x 1080 Pixel |
| Supported video formats | AVC, H.264, H.265, HEVC, M-JPEG, MPEG4 |
| Supported graphic resolutions | 320 x 180 |
| Supported video modes | 1080p |
| Up to 30 frames per second | 60 fps |
| image quality adjustment | Helligkeit, Kontrast, Farbsättigung, Schärfe |
| network | |
| Ethernet interfaces type | Schnelles Ethernet |
| mesh standard | IEEE 802.3at |
| streaming method | Multicasting |
| storage medium | |
| Compatible memory cards | MicroSD (TransFlash), MicroSDHC, MicroSDXC |
| Flash memory | 512 MB |
| storage capacity | 1024 MB |
| ROM capacity | 1024 MB |
| connections and interfaces | |
| Number of Ethernet LAN ports (RJ-45) | 1 |
| safety | |
| Supported security algorithms | EAP-TLS, HTTPS, TLS |
| alert notification type | E-Mail |
| Intelligent Video Surveillance (IVS) system properties | Kreuzungslinie, Gesichtserkennung, Erkennung von Menschen, Moving object, Fahrzeugerkennung |
| energy | |
| energy source | PoE |
| Power consumption (standard operation) | 8 W |
| Power consumption (max.) | 16 W |
| operating conditions | |
| operating temperatur | -30 - 50 °C |
| Storage temperature range | -40 - 65 °C |
| Operating relative humidity | 10 - 100% |
| humidity during storage | 5 - 95% |
| weight and dimensions | |
| broad | 188 mm |
| depth | 188 mm |
| height | 217 mm |
| Weight | 2,5 kg |
| features | |
| scope of delivery | |
| number of cameras | 1 |
| Technical details | |
| sustainability certificates | REACH, RoHS |
| Does not contain | PVC |
| Konformitätsbescheinigungen | REACH, RoHS |
