International Protection (IP) code | IP67 |
Fog proof | Yes |
I code | IK10 |
Product colour | Black |
Mounting Type | Ceiling/Wall/Pole |
Form factor | Dome |
Power source type | DC, PoE |
Power consumption (typical) | 10 W |
Power consumption (max) | 22 W |
DC output voltage | 24 |
Motion sensor | Yes |
Operating temperature (T-T) | -40 - 70 °C |
Web browser | Yes |
Web-based management | Yes |
Weight | 4.7 kg |
Diameter | 19 cm |
Height | 332 mm |
Ethernet LAN | Yes |
Streaming method | Multicast |
Ethernet interface type | Fast Ethernet |
Number of users | 20 user(s) |
Certification | CE: EN55032/EN55024/EN50130-4
FCC: Part15 subpartB, ANSI C63.4-2014
UL: UL60950-1+CAN/CSA C22.2, No.60950-1 |
Wide Dynamic Range (WDR) | Yes |
Placement supported | Indoor & outdoor |
Type | IP security camera |
Day/night mode | Yes |
Alarm input/output | Yes |
Connectivity Technology | Wired |
PACKAGE WEIGHT | 8 kg |
Number of Cameras | 1 |
Signal-to-Noise Ratio (SNR) | 55 dB |
INTERNAL MEMORY | 1024 MB |
Maximum memory card size | 512 GB |
Card reader integrated | Yes |
ROM capacity | 4096 MB |
COMPATIBLE MEMORY CARDS | MicroSD (TransFlash) |
DC-in jack | Yes |
Ethernet LAN (RJ-45) ports | 1 |
Number of Privacy masking areas | 24 |
White balance | Street lamp |
Tilt angle range | -15 - 90° |
Pan speed | 400 °/sec |
Pan range | 0 - 360° |
Lens viewing angle, diagonal | 66.4° |
Camera shutter speed | 1/1 - 1/30,000 s |
Lens viewing angle, horizontal | 58.4° |
Minimum illumination | 0.0005 lx |
Tilt speed | 300 °/sec |
Camera shutter type | Electronic |
Lens viewing angle, vertical | 33.4° |
Tilt manual speed | 0.1 - 200 °/sec |
Pan manual speed | 0.1 - 300 °/sec |
Progressive Scan | Yes |
Optical sensor size | 25.4 / 2.8 mm (1 / 2.8") |
Sensor type | CMOS |
Supported graphics resolutions | 704 x 576 |
Region of Interest (ROI) encoding | Yes |
Noise reduction | Yes |
Video compression formats | H.265 |
Total megapixels | 2 MP |
Frame rate | 30 fps |
Bit rate | 64 kbps–10496 kbps |
Video streaming | Yes |
Gain control type | Auto/Manual |
Bit rate control | Constant Bit Rate (CBR), Variable Bit Rate (VBR) |
Highlight Compensation (HLC) | Yes |
Privacy masking | Yes |
Back Light Compensation (BLC) | Yes |
Noise reduction technology | 2D noise reduction, 3D noise reduction |
Smart IR | Yes |
Maximum Resolution | 1920 x 1080 pixels |
Night Vision | Yes |
LED type | IR |
Optical zoom | 32x |
Focus | Motorized/Manual |
Maximum aperture number | 1.5 |
Minimum aperture number | 4 |
Auto focus | Yes |
Focal length range | 4.5 - 144 mm |
Digital zoom | 16x |
Closest focusing distance | 0.1 m |
