Services | |
Type | IP-Sicherheitskamera |
Unterstützte Positionierung | Innen & Außen |
transmission technology | Kabelgebunden |
Eigenschaft | HTTPS-Verschlüsselung |
Dynamischer Bereich | 120 dB |
Design | |
form factor | Patrone (Form) |
attachment type | Decke/Wand |
Product color | Weiß |
housing material | Kunststoff |
Camera | |
minimum lighting | 0 Lux |
viewing angle (horizontal) | 106 - 30° |
viewing angle (vertical) | 55 - 17° |
Lens viewing angle, diagonal | 127 - 35° |
white balance | ATW, AWC, Drinnen, Manuell, Draußen |
Verschlusstyp | Elektronisch |
Anzahl der Bereiche zur Verdeckung der Privatsphäre | 6 |
image sensor | |
Image sensor size | 25,4 / 2,8 mm (1 / 2.8") |
Sensor-Typ | CMOS |
lens | |
focal range | 3,3 - 10 mm |
Focus | Motorisiert |
Maximum f-number | 3,3 |
Minimum f-number | 1,6 |
Naheinstellgrenze | 0,5 m |
night vision | |
night vision distance | 30 m |
infrared wavelength | 850 nm |
Video | |
Maximum resolution | 1920 x 1080 Pixel |
total megapixels | 2 MP |
Video compression formats | H.264, H.265, M-JPEG |
Supported graphic resolutions | 640 x 360, 640 x 480 (VGA), 720 x 480, 720 x 576, 800 x 448, 800 x 600 (SVGA), 1280 x 720 (HD 720), 1280 x 960, 1920 x 1080 (HD 1080) |
noise canceling technology | Smart Super Noise Reduction (SSNR) |
Bitratenkontrolle | Constant Bit Rate (CBR)/Variable Bit Rate (VBR) |
network | |
streaming method | Multicasting, Unicast |
storage medium | |
Compatible memory cards | MicroSD (TransFlash), SDHC |
Max memory card size | 32 GB |
Flash memory | 256 MB |
storage capacity | 512 MB |
connections and interfaces | |
Number of Ethernet LAN ports (RJ-45) | 1 |
safety | |
Supported security algorithms | EAP-LEAP, EAP-TLS |
energy | |
energy source | PoE |
Power consumption (standard operation) | 5 W |
Power consumption (max.) | 7 W |
operating conditions | |
operating temperatur | -30 - 55 °C |
Storage temperature range | -30 - 55 °C |
Operating relative humidity | 0 - 95% |
humidity during storage | 0 - 95% |
weight and dimensions | |
diameter | 7,8 cm |
Length (mm) | 262 mm |
Weight | 390 g |
scope of delivery | |
number of cameras | 1 |
