| Services | |
| Type | IP-Sicherheitskamera |
| Unterstützte Positionierung | Drinnen |
| transmission technology | Kabelgebunden |
| Eigenschaft | Web-basiertes Management |
| number of languages | 17 |
| Design | |
| form factor | Dome |
| attachment type | Zimmerdecke |
| Product color | Weiß |
| housing material | Kunststoff |
| Camera | |
| minimum lighting | 0,095 Lux |
| rotation angle | 355° |
| tilt angle range | 0 - 67° |
| swivel range | 0 - 350° |
| white balance | ATW, AWC, Drinnen, Manuell, Draußen |
| Verschlusstyp | Elektronisch |
| camera shutter speed | (1/5 - 1/12000 s |
| image sensor | |
| Image sensor size | 25,4 / 2,8 mm (1 / 2.8") |
| Sensor-Typ | CMOS |
| Number of Effective Pixels (H x V) | 1920 x 1080 Pixel |
| lens | |
| Optical zoom | 3,1x |
| focal range | 3.2 - 10 mm |
| Focus | Motorisiert |
| Video | |
| Maximum resolution | 1920 x 1080 Pixel |
| total megapixels | 2 MP |
| Supported video formats | H.264, H.265, M-JPEG |
| Video compression formats | H.264, H.265, M-JPEG |
| Supported graphic resolutions | 640 x 360, 720 x 480, 720 x 576, 800 x 448, 800 x 600 (SVGA), 1280 x 720 (HD 720), 1280 x 960, 1920 x 1080 (HD 1080) |
| Up to 30 frames per second | 30 fps |
| Bitratenkontrolle | Constant Bit Rate (CBR)/Variable Bit Rate (VBR), Variable Bitrate (VBR) |
| Audio | |
| Supported audio formats | G.711, G.726 |
| Samplerate | 8 kHz |
| network | |
| Ethernet interfaces type | Schnelles Ethernet |
| number of users | 6 Benutzer |
| streaming method | Multicasting, Unicast |
| storage medium | |
| Compatible memory cards | MicroSD (TransFlash), MicroSDHC, MicroSDXC |
| Max memory card size | 128 GB |
| Flash memory | 256 MB |
| storage capacity | 512 MB |
| connections and interfaces | |
| Number of Ethernet LAN ports (RJ-45) | 1 |
| Composite video output | 1 |
| safety | |
| Password protection type | Benutzer |
| Supported security algorithms | EAP-TLS, HTTPS, LEAP, SSL/TLS |
| alert notification type | E-Mail |
| Intelligent Video Surveillance (IVS) system properties | Defokussieren, Personenzählung |
| management functions | |
| energy | |
| energy source | Gleichstrom, PoE |
| Power consumption (standard operation) | 5,1 W |
| Power consumption (max.) | 6,5 W |
| Power Consumption (Power over Ethernet (PoE)) | 6 W |
| operating conditions | |
| operating temperatur | -10 - 55 °C |
| Storage temperature range | -30 - 60 °C |
| Operating relative humidity | 5 - 90% |
| humidity during storage | 5 - 90% |
| system requirement | |
| Supports Windows operating systems | Windows 10, Windows 7, Windows 8, Windows 8.1 |
| Supports Mac operating systems | Mac OS X 10.12 Sierra, Mac OS X 10.14 Mojave |
| weight and dimensions | |
| height | 98,8 mm |
| diameter | 12 cm |
| Weight | 320 g |
| scope of delivery | |
| number of cameras | 1 |
