Services | |
Type | IP-Sicherheitskamera |
Unterstützte Positionierung | Innen & Außen |
transmission technology | Kabelgebunden |
Eigenschaft | Webbrowser |
PTZ-Modi | Digitale PTZ, Preset-Punkt |
number of languages | 17 |
Dynamischer Bereich | 150 dB |
Design | |
form factor | Box |
attachment type | Decke/Wand |
Product color | Schwarz |
housing material | Aluminium |
Camera | |
minimum lighting | 0,007 Lux |
white balance | ATW, AWC, Drinnen, Manuell, Draußen |
Verschlusstyp | Elektronisch |
camera shutter speed | 1/12000 s |
image sensor | |
number of sensors | 1 |
Image sensor size | 25,4 / 2,8 mm (1 / 2.8") |
Sensor-Typ | CMOS |
night vision | |
Video | |
Maximum resolution | 1920 x 1080 Pixel |
total megapixels | 2 MP |
Supported video formats | H.264, H.265, M-JPEG |
Up to 30 frames per second | 120 fps |
Bitratenkontrolle | Konstante Bitrate (CBR), Variable Bitrate (VBR) |
Audio | |
Audio input channels | 1 Kanäle |
audio channels | 1 Kanäle |
Supported audio formats | AAC-LC, ADPCM, G.711, G.711 μ-law, G.726 |
network | |
Ethernet interfaces type | Schnelles Ethernet |
number of users | 20 Benutzer |
streaming method | Multicasting, Unicast |
storage medium | |
Compatible memory cards | MicroSD (TransFlash), MicroSDHC, MicroSDXC |
Max memory card size | 512 GB |
Flash memory | 512 MB |
connections and interfaces | |
Number of Ethernet LAN ports (RJ-45) | 1 |
RS-485-Anschlüsse | 1 |
safety | |
Alarm-Eingangskanäle | 2 |
management functions | |
energy | |
energy source | Gleichstrom, PoE |
Power consumption (standard operation) | 9,5 W |
Power consumption (max.) | 19 W |
Power Consumption (Power over Ethernet (PoE)) | 12,9 W |
DC output volts | 12 |
operating conditions | |
operating temperatur | -10 - 55 °C |
Storage temperature range | -50 - 60 °C |
Operating relative humidity | 0 - 95% |
humidity during storage | 0 - 90% |
weight and dimensions | |
broad | 81 mm |
depth | 165 mm |
height | 67 mm |
Weight | 880 g |
scope of delivery | |
number of cameras | 1 |
