Sustainability certificates | RoHS |
Mounting Type | Ceiling/wall |
Housing material | Metal |
Product colour | White |
International Protection (IP) code | IP66 |
Form factor | Dome |
I code | IK10 |
DC output current | 0.9 A |
DC output voltage | 12 |
Power source type | DC, PoE |
Power consumption (Power over Ethernet (PoE)) | 12.9 W |
Video motion detection | Yes |
IP address filtering | Yes |
HTTPS encryption | Yes |
Mirror | Yes |
Heartbeat | Yes |
PASSWORD PROTECTION | Yes |
Anti-flicker | Yes |
Storage relative humidity (H-H) | 0 - 95% |
Operating relative humidity (H-H) | 0 - 95% |
Storage temperature (T-T) | -30 - 60 °C |
Operating temperature (T-T) | -30 - 60 °C |
Behavior analysis | Intrusion detection, Line crossing detection |
Web browser | Yes |
Web-based management | Yes |
Reset button | Yes |
Package depth | 174 mm |
Weight | 830 g |
PACKAGE WEIGHT | 1.71 kg |
Package width | 244 mm |
Height | 133.1 mm |
Package height | 173 mm |
Number of users | 32 user(s) |
Networking standards | IEEE 802.1x |
Ethernet interface type | Fast Ethernet |
Quality of Service (QoS) support | Yes |
Supported network protocols | TCP/IP, ICMP, HTTP, HTTPS, FTP, DHCP, DNS, DDNS, RTP, RTSP, NTP, UPnP, SMTP, IGMP, 802.1X, QoS, IPv6, UDP, Bonjour, SSL/TLS |
Ethernet LAN | Yes |
Wi-Fi | No |
Bluetooth | No |
Day/night mode | Yes |
Placement supported | Outdoor |
Alarm input/output | Yes |
Type | IP security camera |
Connectivity Technology | Wired |
Number of languages | 32 |
Infrared (IR) cut-off filter | Yes |
Number of Cameras | 1 |
Voice Codecs | G.711ulaw |
Audio input channels | 1 channels |
Sample Rate | 48 kHz |
Audio output channels | 1 channels |
Built-in HDD | No |
COMPATIBLE MEMORY CARDS | MicroSDHC |
Maximum memory card size | 256 GB |
Card reader integrated | Yes |
Microphone in | Yes |
Ethernet LAN (RJ-45) ports | 1 |
Viewing angle, diagonal | 138° |
Viewing angle, vertical | 58° |
Viewing angle, horizontal | 113° |
Camera tilt control | Yes |
Camera shutter speed | 1/3 - 1/100000 s |
Tilt angle range | 0 - 75° |
Pan range | 0 - 355° |
Camera pan control | Yes |
Angle of rotation | 355° |
Minimum illumination | 0.002 lx |
Optical sensor size | 25.4 / 2.8 mm (1 / 2.8") |
Sensor type | CMOS |
Progressive Scan | Yes |
Number of sensors | 1 |
Region of Interest (ROI) encoding | Yes |
Image quality adjustment | Sharpness |
Video compression formats | H.264+ |
Bit rate control | Constant Bit Rate (CBR)/Variable Bit Rate (VBR) |
Privacy masking | Yes |
Noise reduction | Yes |
Noise reduction technology | 3D noise reduction |
Video streaming | Yes |
Highlight Compensation (HLC) | Yes |
Supported graphics resolutions | 640 x 480 (VGA) |
Back Light Compensation (BLC) | Yes |
Total megapixels | 2 MP |
Maximum Resolution | 1920 x 1080 pixels |
Frame rate | 30 fps |
Night Vision | Yes |
LED type | IR |
Night vision distance | 40 m |
Infra-red wavelength | 850 nm |
Auto focus | Yes |
Maximum aperture number | 1.4 |
Focal length range | 2.8 - 12 mm |
Number of lenses | 1 |
