Housing material | Metal |
Product colour | White |
International Protection (IP) code | IP67 |
Form factor | Bullet |
Protection features | Waterproof |
Mounting Type | Ceiling/wall |
Power consumption (max) | 10.5 W |
Power source type | DC, PoE |
DC output voltage | 12 |
Power consumption (Power over Ethernet (PoE)) | 17 W |
DC output current | 1.4 A |
Security algorithms | EAP-LEAP |
Alarm input channels | 1 |
Alarm output channels | 1 |
Digest authentication | Yes |
Human and vehicle targets classification | Yes |
Network access storage (NAS) | Yes |
Audit log | Yes |
Flash log | Yes |
Automatic Network Replenishment (ANR) | Yes |
Pixel counter | Yes |
Password reset via email | Yes |
Privacy protection | Yes |
Digital watermark | Yes |
HTTPS encryption | Yes |
Video motion detection | Yes |
IP address filtering | Yes |
PASSWORD PROTECTION | Yes |
Mirror | Yes |
Heartbeat | Yes |
Active tampering alarm | Yes |
Operating relative humidity (H-H) | 0 - 95% |
Operating temperature (T-T) | -30 - 60 °C |
Storage relative humidity (H-H) | 0 - 95% |
Storage temperature (T-T) | -30 - 60 °C |
Reset button | Yes |
Web-based management | Yes |
Behavior analysis | Line crossing detection |
Web browser | Yes |
Length | 286.7 mm |
Weight | 1.21 kg |
Width | 93.1 mm |
Height | 91.2 mm |
Quality of Service (QoS) support | Yes |
Networking standards | IEEE 802.1x |
Wi-Fi | No |
Ethernet LAN | Yes |
Ethernet interface type | Fast Ethernet |
Bluetooth | No |
Number of simultaneous live view channels | 6 channels |
User access level | Administrator, Operator, User |
Client interoperability | iVMS-4200, Hik-Connect, Hik-Central |
Live view | Yes |
Number of users | 32 user(s) |
Certification | FCC (47 CFR 15, B); CE-EMC (EN 55032: 2015, EN 61000-3-2: 2014, EN 61000-3-3: 2013, EN 50130-4: 2011 +A1: 2014); RCM (AS/NZS CISPR 32: 2015); IC (ICES-003: 6, 2016); KC (KN 32: 2015, KN 35: 2015) |
Wide Dynamic Range (WDR) | Yes |
Connectivity Technology | Wired |
Type | IP security camera |
Number of languages | 33 |
Placement supported | Outdoor |
Dynamic range | 120 dB |
Infrared (IR) cut-off filter | Yes |
Languages support | Multi |
Day/night mode | Yes |
Package depth | 156 mm |
Package height | 155 mm |
Package width | 386 mm |
PACKAGE WEIGHT | 1.9 kg |
Number of Cameras | 1 |
Audio input channels | 1.0 channels |
Audio output channels | 1.0 channels |
Built-in microphone | Yes |
Signal-to-Noise Ratio (SNR) | 52 dB |
Sample rates | 8 - 48 kHz |
Bit rate range | 8 - 320 Kbit/s |
Number of microphones | 2 |
Audio codecs | G.711/G.722.1/G.726/MP2L2/PCM/MP3/AAC-LC |
COMPATIBLE MEMORY CARDS | MicroSDXC |
Card reader integrated | Yes |
Built-in HDD | No |
Maximum memory card size | 512 GB |
Ethernet LAN (RJ-45) ports | 1 |
Terminal block port | Yes |
Camera shutter speed | 1/3 - 1/100000 s |
Tilt angle range | 0 - 90° |
Pan range | 0 - 360° |
Angle of rotation | 360° |
Minimum illumination | 0 lx |
Lens viewing angle, vertical | 55° |
Lens viewing angle, horizontal | 100° |
Number of Privacy masking areas | 4 |
Lens viewing angle, diagonal | 120° |
Browser supported | IE 10, IE 11, Chrome 57.0+, Firefox 52.0+ |
Optical sensor size | 25.4 / 3 mm (1 / 3") |
Progressive Scan | Yes |
Sensor type | CMOS |
Number of sensors | 1 |
Supported graphics resolutions | 1920 x 1080 (HD 1080) |
Frame rate | 30 fps |
Maximum Resolution | 2688 x 1520 pixels |
Bit rate | 32 Kbps - 8 Mbps |
Highlight Compensation (HLC) | Yes |
Back Light Compensation (BLC) | Yes |
Total megapixels | 4 MP |
Noise reduction | Yes |
Video compression formats | M-JPEG |
Video streaming | Yes |
Gain control type | Auto |
Image quality adjustment | Contrast |
Region of Interest (ROI) encoding | Yes |
Noise reduction technology | 3D noise reduction |
Privacy masking | Yes |
Bit rate control | Constant Bit Rate (CBR)/Variable Bit Rate (VBR) |
Video recording | Yes |
LED type | IR |
Night vision distance | 60 m |
Infra-red wavelength | 850 nm |
Night Vision | Yes |
Identify distance | 6 m |
Maximum aperture number | 1 |
Fixed focal length | 2.8 mm |
Detect distance | 63 m |
Observe distance | 25 m |
Recognize distance | 12 m |
Number of lenses | 1 |
Warnings | The product contains electronic components; do not dispose of with the normal household waste. |
Compliance certificates | Federal Communications Commission (FCC) |
