Sustainability certificates | CE |
Form factor | Dome |
I code | IK10 |
International Protection (IP) code | IP67 |
Housing material | Metal |
Product colour | White |
Mounting Type | Ceiling/wall |
Power source type | DC, PoE |
Power consumption (max) | 5 W |
Power consumption (Power over Ethernet (PoE)) | 6.5 W |
DC output current | 0.4 A |
DC output voltage | 12 |
HTTPS encryption | Yes |
IP address filtering | Yes |
Intelligent Video Surveillance (IVS) system features | Scene change |
Heartbeat | Yes |
PASSWORD PROTECTION | Yes |
Video motion detection | Yes |
Anti-flicker | Yes |
Mirror | Yes |
Operating temperature (T-T) | -30 - 60 °C |
Storage temperature (T-T) | -30 - 60 °C |
Storage relative humidity (H-H) | 0 - 95% |
Operating relative humidity (H-H) | 0 - 95% |
Reset button | Yes |
WPS push button | Yes |
Web-based management | Yes |
Behavior analysis | Intrusion detection, Line crossing detection, Region entrance detection, Region exiting detection |
Package width | 150 mm |
Package height | 141 mm |
PACKAGE WEIGHT | 820 g |
Diameter | 12.1 cm |
Package depth | 150 mm |
Weight | 580 g |
Wi-Fi | No |
Ethernet interface type | Fast Ethernet |
Ethernet LAN | Yes |
Quality of Service (QoS) support | Yes |
Number of users | 32 user(s) |
Bluetooth | No |
Networking standards | IEEE 802.1x |
Certification | FCC (47 CFR 15, B); CE-EMC (EN 55032: 2015, EN 61000-3-2: 2014, EN 61000-3-3: 2013, EN 50130-4: 2011 + A1: 2014); RCM (AS/NZS CISPR 32: 2015); KC (KN 32: 2015, KN 35: 2015)UL (UL 60950-1); CB (IEC 60950-1: 2005 + Am 1: 2009 + Am 2: 2013, IEC 62368-1: 2014 ); CE-LVD (EN 60950-1: 2005 + Am 1: 2009 + Am 2: 2013, IEC 62368-1: 2014 ); LOA (IEC/EN 60950-1)CE-RoHS (2011/65/EU); WEEE (2012/19/EU); Reach ( (EC) No 1907/2006) |
Wide Dynamic Range (WDR) | Yes |
Type | IP security camera |
Day/night mode | Yes |
Connectivity Technology | Wired |
Languages support | Multi |
Infrared (IR) cut-off filter | Yes |
Number of languages | 33 |
Placement supported | Outdoor |
Alarm input/output | Yes |
Number of Cameras | 1 |
Voice Codecs | MP2L2 |
Audio formats supported | MP3 |
Sample Rate | 48 kHz |
Built-in microphone | Yes |
Card reader integrated | Yes |
COMPATIBLE MEMORY CARDS | MicroSDHC |
Built-in HDD | No |
Maximum memory card size | 256 GB |
Ethernet LAN (RJ-45) ports | 1 |
Pan range | 0 - 355° |
Angle of rotation | 355° |
Camera shutter speed | 1/3 - 1/100000 s |
Camera tilt control | Yes |
Camera pan control | Yes |
Lens viewing angle, vertical | 55° |
Lens viewing angle, diagonal | 123° |
Lens viewing angle, horizontal | 103° |
Tilt angle range | 0 - 75° |
Harmonized System (HS) code | 85258900 |
Progressive Scan | Yes |
Sensor type | CMOS |
Optical sensor size | 25.4 / 3 mm (1 / 3") |
Number of sensors | 1 |
Back Light Compensation (BLC) | Yes |
Supported graphics resolutions | 1920 x 1080 (HD 1080) |
Bit rate | 32 Kbps - 8 Mbps |
Noise reduction | Yes |
Video compression formats | H.265 |
Highlight Compensation (HLC) | Yes |
Noise reduction technology | 3D noise reduction |
Image quality adjustment | Saturation |
Region of Interest (ROI) encoding | Yes |
Maximum Resolution | 2688 x 1520 pixels |
Total megapixels | 4 MP |
Privacy masking | Yes |
Video streaming | Yes |
Frame rate | 30 fps |
LED type | IR |
Night vision distance | 30 m |
Infra-red wavelength | 850 nm |
Night Vision | Yes |
Maximum aperture number | 1.4 |
Number of lenses | 1 |
Recognize distance (wide) | 12 m |
Identify distance (wide) | 6 m |
Fixed focal length | 2.8 mm |
