Product colour | White |
Form factor | Turret |
Mounting Type | Ceiling/wall |
International Protection (IP) code | IP66 |
Power consumption (max) | 9 W |
Power source type | DC, PoE |
Current | 750 mA |
DC output voltage | 12 |
Mirror | Yes |
Video motion detection | Yes |
PASSWORD PROTECTION | Yes |
Digital watermark | Yes |
Operating relative humidity (H-H) | 0 - 95% |
Operating temperature (T-T) | -30 - 40 °C |
Web-based management | Yes |
Reset button | Yes |
Package height | 289 mm |
Package depth | 205 mm |
Width | 120 mm |
Weight | 700 g |
Package width | 167 mm |
Depth | 162 mm |
Package tare weight | 1250 g |
Quality of Service (QoS) support | Yes |
Networking standards | IEEE 802.3af |
Bluetooth | No |
Wi-Fi | No |
Ethernet LAN | Yes |
Certification | FCC (47 CFR Part 15, Subpart B); CE-EMC (EN 55032: 2015, EN 61000-3-2: 2014, EN 61000-3-3: 2013, EN 50130-4: 2011, +A1: 2014); IC (ICES-003: Issue 6, 2016) |
Type | IP security camera |
Connectivity Technology | Wired |
PTZ control | Yes |
Infrared (IR) cut-off filter | Yes |
Placement supported | Outdoor |
Wide Dynamic Range (WDR) | Yes |
Day/night mode | Yes |
Number of Cameras | 1 |
Built-in microphone | Yes |
Sample Rate | 16 kHz |
Voice Codecs | PCM |
Built-in speaker(s) | Yes |
Card reader integrated | Yes |
COMPATIBLE MEMORY CARDS | MicroSD (TransFlash) |
Built-in HDD | No |
Maximum memory card size | 256 GB |
Ethernet LAN (RJ-45) ports | 1 |
Lens viewing angle, horizontal | 111.4° |
Tilt angle range | -5 - 105° |
Lens viewing angle, vertical | 59.1° |
Pan range | 0 - 340° |
Pan preset speed | 4 °/sec |
Camera tilt control | Yes |
Camera pan control | Yes |
Sensor type | CMOS |
Progressive Scan | Yes |
Optical sensor size | 25.4 / 2.7 mm (1 / 2.7") |
Number of sensors | 1 |
Supported graphics resolutions | 1920 x 1080 (HD 1080) |
Maximum Resolution | 1920 x 1080 pixels |
Digital Wide Dynamic Range (DWDR) | Yes |
Bit rate | 32 Kbps - 8 Mbps |
Image quality adjustment | Contrast |
Total megapixels | 2 MP |
Noise reduction technology | 3D noise reduction |
Highlight Compensation (HLC) | Yes |
Back Light Compensation (BLC) | Yes |
Video streaming | Yes |
Video compression formats | H.264 |
Frame rate | 25 fps |
Noise reduction | Yes |
Night Vision | Yes |
LED type | IR / White light LED |
Night vision distance | 30 m |
Infra-red wavelength | 850 nm |
Focal length range | 2.8 mm |
Maximum aperture number | 1.6 |
