storage medium | |
storage drive interface | Serial ATA III |
Supported storage drive interfaces | M.2, Serial ATA II, Serial ATA III |
supported storage drive sizes | 2.5,3.5,M.2 |
Number of installed system drives | 1 |
System Drive Capacity | 5 GB |
Number of M.2 (M & B) slots | 2 |
Eigenschaft | Unterstützte Linux-Betriebssysteme |
RAID Level | 0, 1, 5, 6, 10, 50, 60, JBOD |
Supported file systems | FAT32, HFS+, NTFS, exFAT, ext3, ext4 |
Number of supported storage drives | 8 |
Supported storage drives | HDD & SSD |
processor | V1500B |
processor manufacturer | AMD |
processor family | Ryzen Embedded |
processor clock speed | 2,2 GHz |
number of CPU cores | 4 |
processor threads | 8 |
Number of processors supported | 1 |
Storage | |
storage capacity | 8 GB |
Internal storage type | DDR4 |
Maximum supported RAM | 64 GB |
memory card slots | 2 |
Memory form factor | SO-DIMM |
Flash memory | 5000 MB |
network | |
Ethernet LAN data transfer rates | 100,1000,2500 Mbit/s |
connections and interfaces | |
USB 3.2 Gen 1 (3.1 Gen 1) Number of Type-C ports | 1 |
USB 3.2 Gen 2 (3.1 Gen 2) Number of Type A ports | 3 |
Number of Ethernet LAN ports (RJ-45) | 2 |
Simultaneous Connections | 2000 |
PCI Express x4 (Gen 3.x) connectors | 2 |
Design | |
case type | Tower |
cooling | Aktiv |
Product color | Schwarz |
number of fans | 3 Lüfter |
fan diameter | 12 cm |
Diameter fan 2 | 6 cm |
LED indicators | HDD, Leistung, SSD, Status, USB |
Lock-Type Cable Barrier | Kensington |
Services | |
Type | NAS |
device class | Kleines & Mittleres Unternehmen |
backup functions | Cloud, iSCSI LUN |
noise level | 23 dB |
Software | |
Installed operating system | QNAP Turbo System |
version of the operating system | 5,0,0 |
Supports Windows operating systems | Windows 10, Windows 7, Windows 8 |
Supports Mac operating systems | Mac OS X 10.10 Yosemite |
Supported server operating systems | Windows Server 2008 R2, Windows Server 2012, Windows Server 2012 R2, Windows Server 2016, Windows Server 2019 |
energy | |
Power supply placement | Eingebaut |
capacity of the power supply unit | 250 W |
Power consumption (standard operation) | 54,067 W |
Power consumption (sleep mode) | 25,668 W |
Power consumption (HDD standby) | 25,668 W |
AC input voltage | 100 - 240 V |
AC input frequency | 50 - 60 Hz |
weight and dimensions | |
broad | 329,3 mm |
depth | 280,8 mm |
height | 188,2 mm |
Weight | 6,76 kg |
scope of delivery | |
Supplied cables | LAN (RJ-45) |
Anzahl Stromkabel | 1 |
operating conditions | |
operating temperatur | 0 - 40 °C |
Operating relative humidity | 5 - 95% |
Storage temperature range | -20 - 70 °C |
logistic data | |
Goods tariff number (HS) | 84714100 |
