Processor frequency | 2.2 GHz |
Processor cores | 4 |
Processor threads | 8 |
Processor family | Ryzen Embedded |
Processor manufacturer | AMD |
Processor model | V1500B |
Processor generation | AMD Ryzen Embedded V1000 Series |
Internal memory type | DDR4 |
INTERNAL MEMORY | 4 GB |
ETC | Yes |
Memory Form Factor | SO-DIMM |
Memory slots | 2 |
Maximum RAM supported | 32 GB |
Product colour | Black |
LED indicators | Yes |
Cooling type | Active |
Drive bay locking | Yes |
Fan diameter 2 | 9.2 cm |
Fan Diameter | 9.2 cm |
Number of fans | 2 fan(s) |
AC input frequency | 50 - 60 Hz |
Power consumption (typical) | 37.91 W |
AC input voltage | 100 - 240 V |
Power supply location | External |
Power consumption (HDD standby) | 12.33 W |
Power supply unit (PSU) capacity | 100 W |
Operating relative humidity (H-H) | 5 - 95% |
Operating temperature (T-T) | 0 - 40 °C |
Storage relative humidity (H-H) | 5 - 95% |
Storage temperature (T-T) | -20 - 60 °C |
Depth | 223 mm |
Weight | 2.26 kg |
Width | 199 mm |
Height | 166 mm |
Ethernet LAN data rates | 2500 Mbit/s |
Wake-on-LAN ready | Yes |
Ethernet LAN | Yes |
Supported network protocols | SMB1 (CIFS), SMB2, SMB3, NFSv3, NFSv4, NFSv4.1, NFS Kerberized sessions, iSCSI, HTTP, HTTPs, FTP, SNMP, LDAP, CalDAV |
Noise level | 20.5 dB |
Type | NAS |
On/off switch | Yes |
Web-based management | Yes |
Snapshot | Yes |
System log | No |
Browser supported | Chrome,Firefox,Edge,Safari |
Access Control List (ACL) | Yes |
Backup features | iSCSI LUN |
Number of users | 512 user(s) |
Multilingual support | Yes |
Device class | Home & Home Office |
Backup function | Yes |
CABLES INCLUDED | LAN (RJ-45) |
Power cables quantity | 1 |
External power adapter | Yes |
RAID levels | JBOD |
Raid Support | Yes |
Supported storage drive interfaces | M.2, Serial ATA |
Supported storage drive types | HDD & SSD |
Number of storage drives supported | 9 |
Maximum supported storage capacity | 180 TB |
Storage drive sizes supported | M.2 |
Installed storage drive type | No |
Supported file systems | exFAT |
Storage drives installed | No |
Number of M.2 (M & B) slots | 2 |
Storage drive interface | M.2, Serial ATA |
Storage Drive Capacity | 0 GB |
Total installed storage capacity | 0 TB |
Hot-swap drive bays | Yes |
Ethernet LAN (RJ-45) ports | 2 |
USB 3.2 Gen 1 (3.1 Gen 1) Type-A ports quantity | 2 |
USB Port | Yes |
Certification | FCC
CE
BSMI
VCCI
RCM
UKCA
EAC
CCC
KC
BIS |
Compliance certificates | RoHS |
Warranty period | 3 year(s) |
