storage medium | |
storage capacity | 16 GB |
Supported storage drive interfaces | SATA, Serial ATA II, Serial ATA III |
supported storage drive sizes | 2.5,3.5" |
Maximum supported storage capacity | 200 TB |
Eigenschaft | Intel® VT-x mit Extended Page Tables (EPT) |
RAID Level | 0, 1, 5, 6, 10, JBOD |
Supported file systems | BTRFS, Fett, HFS+, NTFS, ext3, ext4 |
Total installed storage capacity | 0 TB |
Number of supported storage drives | 12 |
Supported storage drives | HDD & SSD |
processor | D-1531 |
processor manufacturer | Intel |
processor family | Intel® Xeon® D |
processor clock speed | 2,2 GHz |
Processor Boost Frequency | 2,7 GHz |
number of CPU cores | 6 |
CPU configuration (max) | 1 |
Number of processors supported | 1 |
Storage | |
Internal storage type | DDR4 |
Maximum supported RAM | 48 GB |
memory card slots | 4 |
Memory form factor | SO-DIMM |
network | |
Ethernet LAN data transfer rates | 1000,10000 Mbit/s |
Supported network protocols | SMB1 (CIFS), SMB2, SMB3, NFSv3, NFSv4, NFSv4.1, NFS Kerberized sessions, iSCSI, HTTP, HTTPs, FTP, SNMP, LDAP, CalDAV |
connections and interfaces | |
USB 3.2 Gen 1 (3.1 Gen 1) Number of Type A ports | 2 |
Number of Ethernet LAN ports (RJ-45) | 4 |
PCI Express x8 (Gen 3.x) connectors | 1 |
Design | |
case type | Tower |
cooling | Aktiv |
Product color | Schwarz |
number of fans | 2 Lüfter |
fan diameter | 12 cm |
Diameter fan 2 | 12 cm |
Services | |
Type | NAS |
device class | Home & Home Office |
noise level | 25 dB |
Supported browser | Safari, Google Chrome, Firefox, Microsoft Edge |
Software | |
Installed operating system | DiskStation Manager |
Supported server operating systems | Windows Server 2016, Windows Server 2019 |
energy | |
Power supply placement | Eingebaut |
capacity of the power supply unit | 550 W |
Number of power supply units | 1 |
Power consumption (standard operation) | 94,42 W |
Power consumption (HDD standby) | 54,33 W |
AC input voltage | 100 - 240 V |
AC input frequency | 50 - 60 Hz |
weight and dimensions | |
broad | 300 mm |
depth | 340 mm |
height | 270 mm |
Weight | 9,8 kg |
scope of delivery | |
Supplied cables | AC, LAN (RJ-45) |
Processor specifics | |
Intel® Secure Key Technologieversion | 1,00 |
Intel® TSX-NI-Version | 1,00 |
operating conditions | |
operating temperatur | 0 - 40 °C |
Operating relative humidity | 5 - 95% |
Storage temperature range | -20 - 60 °C |
logistic data | |
Goods tariff number (HS) | 84714100 |
Other functions | |
certification | FCCCEBSMIVCCIRCMUKCAEACKCUL |
