Processor model | V1780B |
Processor boost frequency | 3.6 GHz |
Processor cores | 4 |
Processor frequency | 3.35 GHz |
Processor manufacturer | AMD |
Number of processors supported | 1 |
Processor family | Ryzen Embedded |
Processor generation | AMD Ryzen Embedded V1000 Series |
Memory Form Factor | UDIMM |
INTERNAL MEMORY | 8 GB |
ETC | Yes |
Internal memory type | DDR4 |
Memory slots | 2 |
Maximum RAM supported | 32 GB |
Cooling type | Active |
Built-in Display | No |
LED indicators | Yes |
Product colour | Grey |
Number of fans | 3 fan(s) |
Fan Diameter | 6 cm |
Built-in speaker(s) | No |
Chassis type | Rack (2U) |
Power consumption (typical) | 119.95 W |
AC input voltage | 100 - 240 V |
AC input frequency | 50 - 60 Hz |
Redundant power supply (RPS) support | No |
Power supply location | Built-in |
Power supply unit (PSU) capacity | 500 W |
Number of power supply units | 1 |
Operating temperature (T-T) | 0 - 35 °C |
Operating relative humidity (H-H) | 5 - 95% |
Storage temperature (T-T) | -20 - 60 °C |
Weight | 11.5 kg |
Width | 482 mm |
Depth | 562 mm |
Height | 88 mm |
Ethernet LAN data rates | 1000 Mbit/s |
Ethernet LAN | Yes |
Wake-on-LAN ready | Yes |
iSCSI support | Yes |
Copper ethernet cabling technology | 1000BASE-T |
Link aggregation | Yes |
Ethernet LAN data rate supported (max) | 10000 Mbit/s |
Noise level | 52.3 dB |
Card reader integrated | No |
Type | NAS |
Security algorithms | AES |
Browser supported | Google Chrome Firefox Microsoft Edge Safari |
Backup function | Yes |
Snapshot | Yes |
Backup features | Cloud |
Device class | Small & Medium Business |
Access Control List (ACL) | Yes |
Built-in FTP server | Yes |
Management protocols | SNMP |
Multilingual support | Yes |
System log | Yes |
CABLES INCLUDED | AC |
External power adapter | No |
Rack mount kit | Yes |
Power cables quantity | 1 |
Operating system installed | DiskStation Manager |
Operating System Version | 7.1.1 |
Raid Support | Yes |
Supported storage drive interfaces | Serial ATA |
RAID levels | JBOD |
Number of storage drives supported | 12 |
Supported storage drive types | HDD & SSD |
Storage drives installed | No |
Total installed storage capacity | 0 TB |
Installed storage drive type | No |
Online RAID expansion | Yes |
Storage drive sizes supported | 2.5 |
Hot-swap drive bays | Yes |
Supported file systems | ext4 |
Online RAID migration | Yes |
Ethernet LAN (RJ-45) ports | 3 |
USB 3.2 Gen 1 (3.1 Gen 1) Type-A ports quantity | 2 |
PCI Express x8 (Gen 3.x) slots | 1 |
USB Port | Yes |
Certification | FCC
BSMI
VCCI
RCM
UKCA
EAC
CCC
KC
UL |
Compliance certificates | RoHS |
Sustainability compliance | Yes |
