storage medium | |
storage capacity | 8 GB |
Supported storage drive interfaces | Serial Attached SCSI (SAS) |
supported storage drive sizes | 2.5,3.5" |
Maximum supported storage capacity | 192 TB |
Eigenschaft | UART |
RAID Level | 0, 1, 5, 6, 10, F1, JBOD |
Supported file systems | BTRFS |
Total installed storage capacity | 0 TB |
Number of supported storage drives | 12 |
Supported storage drives | HDD & SSD |
processor | D-1521 |
processor manufacturer | Intel |
processor family | Intel® Xeon® D |
processor clock speed | 2,4 GHz |
Processor Boost Frequency | 2,7 GHz |
number of CPU cores | 4 |
processor threads | 8 |
processor cache | 6 MB |
CPU configuration (max) | 1 |
PCI Express configurations | 1x16, 1x4, 1x8 |
PCI-Express-Slots-Version | 2.0, 3.0 |
processor code | SR2DF |
Processor code name | Broadwell |
Processor lithography | 14 nm |
Processor Operating Modes | 64-Bit |
Processor Package Size | 37.5 x 37.5 mm |
processor series | Intel Xeon D-1500 |
processor socket | BGA 1667 |
scalability | 1S |
Stepping | V2 |
Thermal Design Power (TDP) | 45 W |
Maximum internal memory supported by the processor | 128 GB |
Storage | |
Internal storage type | DDR4 |
Maximum supported RAM | 64 GB |
memory card slots | 4 |
Memory form factor | UDIMM |
network | |
Ethernet LAN data transfer rates | 1000,10000 Mbit/s |
Supported Ethernet LAN data rate (max.) | 10000 Mbit/s |
Supported network protocols | iSCSI, Telnet, SSH, SNMP |
connections and interfaces | |
Number of Ethernet LAN ports (RJ-45) | 3 |
PCI Express x8 (Gen 3.x) connectors | 1 |
Design | |
case type | Rack (2U) |
cooling | Aktiv |
Product color | Schwarz, Grau |
number of fans | 2 Lüfter |
fan diameter | 6 cm |
LED indicators | Leistung, Status |
Services | |
Type | SAN |
device class | Kleines & Mittleres Unternehmen |
backup functions | iSCSI LUN |
noise level | 51,3 dB |
Supported browser | Chrome, Firefox, Edge,Internet Explorer 10+, Safari 10+, Chrome |
Software | |
Supported server operating systems | Windows Server 2008, Windows Server 2012, Windows Server 2013, Windows Server 2016 |
Support for other operating systems | Solaris 10, Solaris 11, VMware ESX/ESXi 5.0, VMware ESX/ESXi 5.1, VMware ESX/ESXi 6.0, VMware ESX/ESXi 6.5 |
energy | |
Power supply placement | Eingebaut |
capacity of the power supply unit | 500 W |
Number of power supply units | 1 |
Power consumption (standard operation) | 417,48 W |
Power consumption (HDD standby) | 274,38 W |
AC input voltage | 100 - 240 V |
AC input frequency | 50 - 60 Hz |
weight and dimensions | |
broad | 482 mm |
depth | 724 mm |
height | 88 mm |
Weight | 19,7 kg |
scope of delivery | |
Supplied cables | AC |
Processor specifics | |
Intel® Secure Key Technologieversion | 1,00 |
Intel® TSX-NI-Version | 1,00 |
Intel® Turbo-Boost Technology | 2.0 |
Maximum number of PCI Express lanes | 32 |
Memory types supported by the processor | DDR3-SDRAM, DDR4-SDRAM |
operating conditions | |
operating temperatur | 0 - 35 °C |
Operating relative humidity | 5 - 95% |
Storage temperature range | -20 - 60 °C |
humidity during storage | 5 - 95% |
operating height | 0 - 5000 m |
logistic data | |
Goods tariff number (HS) | 84714100 |
Other functions | |
Konformitätsbescheinigungen | RoHS |
certification | EACVCCICCCRCMKCFCCCEBSMI |
ARK processor detection | 91202 |
