management functions | |
Switch-Typ | Managed |
switch level | L2 |
Eigenschaft | Rackmontageset |
connections and interfaces | |
Number of basic switching RJ-45 Ethernet ports | 24 |
Basic Switching RJ-45 Ethernet Ports-Typ | Gigabit Ethernet (10/100/1000) |
Number of combo SPF ports | 2 |
network | |
mesh standard | IEEE 802.1D, IEEE 802.1ab, IEEE 802.1p, IEEE 802.1w, IEEE 802.3, IEEE 802.3ad, IEEE 802.3af, IEEE 802.3at, IEEE 802.3u, IEEE 802.3x, IEEE 802.3z |
Copper Ethernet cabling technology | 10BASE-T, 100BASE-TX, 1000BASE-T |
Virtual LAN functions | MAC address-based VLAN, Port-based VLAN |
Number of VLANs | 256 |
optical fiber | |
Ethernet cable cabling technology | 1000BASE-X |
data transmission | |
Routing/Switching Capacity | 52 Gbit/s |
Transferrate | 38,7 Mpps |
MAC-Adressentabelle | 8000 Eintragungen |
Data packet buffer memory | 0,525 MB |
safety | |
DHCP functions | DHCP client, DHCP relay, DHCP snooping |
Supported security algorithms | SNMP, SNMPv3, SSH, SSL/TLS |
Queue Scheduling Algorithms | SPQ, WFQ, Weighted Round Robin (WRR) |
multicast capabilities | |
Design | |
Product color | Grau |
Electromagnetic compatibility | CE, FCC, C-Tick, A; BSMI CNS13438 |
Services | |
noise level | 40,1 dB |
Mean Time Between Failures (MTBF) | 888495 h |
energy | |
AC input voltage | 100 - 240 V |
AC input frequency | 50 - 60 Hz |
Power consumption (max.) | 448,9 W |
Power Over Ethernet (PoE) | |
Number of Power over Ethernet (PoE) ports | 24 |
Overall Power over Ethernet (PoE) | 375 W |
operating conditions | |
operating temperatur | -20 - 50 °C |
Storage temperature range | -40 - 70 °C |
Operating relative humidity | 5 - 95% |
humidity during storage | 5 - 95% |
heat dissipation | 1530,75 BTU/h |
weight and dimensions | |
broad | 441 mm |
depth | 270 mm |
height | 44 mm |
Weight | 3,58 kg |
scope of delivery | |
Supplied cables | AC |
logistic data | |
Goods tariff number (HS) | 85176990 |
