management functions | |
Switch-Typ | Managed |
switch level | L2 |
Eigenschaft | Netzteil enthalten |
connections and interfaces | |
Number of basic switching RJ-45 Ethernet ports | 24 |
Basic Switching RJ-45 Ethernet Ports-Typ | Gigabit Ethernet (10/100/1000) |
network | |
mesh standard | IEEE 802.1p, IEEE 802.3, IEEE 802.3ab, IEEE 802.3af, IEEE 802.3at, IEEE 802.3az, IEEE 802.3u, IEEE 802.3x |
Ethernet LAN data transfer rates | 100,1000 Mbit/s |
Virtual LAN functions | Port-based VLAN |
data transmission | |
Routing/Switching Capacity | 48 Gbit/s |
Transferrate | 35,7 Mpps |
MAC-Adressentabelle | 8000 Eintragungen |
Jumbo-Frames | 9000 |
Data packet buffer memory | 525 MB |
safety | |
DHCP functions | DHCP client, DHCP relay |
Supported security algorithms | HTTPS, SHA-2, SSH-2, SSL/TLS |
multicast capabilities | |
logs | |
management logs | SNMP v1, v2c, v3 |
Design | |
form factor | 1U |
Product color | Schwarz |
Services | |
Mean Time Between Failures (MTBF) | 674068 h |
energy | |
energy source | AC |
AC input voltage | 100 - 240 V |
AC input frequency | 50 - 60 Hz |
Power consumption (max.) | 15,5 W |
operating conditions | |
operating temperatur | 0 - 40 °C |
Storage temperature range | -40 - 70 °C |
Operating relative humidity | 10 - 95% |
heat dissipation | 53 BTU/h |
weight and dimensions | |
broad | 267 mm |
depth | 162 mm |
height | 42 mm |
Weight | 1,57 kg |
package weight | 2,05 kg |
