management functions | |
Switch-Typ | Managed |
switch level | L2+ |
Eigenschaft | AC-Netzadapter |
connections and interfaces | |
Number of basic switching RJ-45 Ethernet ports | 8 |
Basic Switching RJ-45 Ethernet Ports-Typ | Gigabit Ethernet (10/100/1000) |
Number of Gigabit Ethernet (copper) ports | 8 |
Quantity of SFP module slots | 2 |
network | |
mesh standard | IEEE 802.3, IEEE 802.3ab, IEEE 802.3u, IEEE 802.3x, IEEE 802.3z |
Copper Ethernet cabling technology | 10BASE-T, 100BASE-TX, 1000BASE-T |
Virtual LAN functions | Tagged VLAN |
data transmission | |
Routing/Switching Capacity | 16 Gbit/s |
MAC-Adressentabelle | 4096 Eintragungen |
number of queues | 7 |
Jumbo-Frames | 9216 |
safety | |
Queue Scheduling Algorithms | WFQ, SP |
multicast capabilities | |
Number of filtered multicast groups | 256 |
logs | |
management logs | HTTP, HTTPS |
Design | |
Product color | Schwarz |
housing material | Metall |
certification | CE |
Services | |
buffer size | 1500 KB |
energy | |
output voltage | 55 V |
output current | 1,3 A |
Power Over Ethernet (PoE) | |
Number of Power over Ethernet plus (PoE+) ports | 4 |
Overall Power over Ethernet (PoE) | 50 W |
operating conditions | |
Operating relative humidity | 10 - 90% |
weight and dimensions | |
broad | 240 mm |
depth | 105 mm |
height | 27 mm |
