management functions | |
Switch-Typ | Unmanaged |
Eigenschaft | Power over Ethernet (PoE) |
connections and interfaces | |
Number of basic switching RJ-45 Ethernet ports | 8 |
Basic Switching RJ-45 Ethernet Ports-Typ | Gigabit Ethernet (10/100/1000) |
network | |
mesh standard | IEEE 802.1p, IEEE 802.3af, IEEE 802.3at, IEEE 802.3az, IEEE 802.3x |
data transmission | |
Routing/Switching Capacity | 16 Gbit/s |
MAC-Adressentabelle | 4000 Eintragungen |
Jumbo-Frames | 9000 |
Design | |
Product color | Schwarz |
Services | |
buffer size | 192 KB |
Mean Time Between Failures (MTBF) | 2752476 h |
energy | |
energy source | Gleichstrom |
DC input voltage | 54 V |
output voltage | 2.4 V |
Power consumption (standard operation) | 123 W |
Power Over Ethernet (PoE) | |
Number of Power over Ethernet plus (PoE+) ports | 8 |
Power over Ethernet (PoE) performance per port | 30 W |
Overall Power over Ethernet (PoE) | 123 W |
operating conditions | |
operating temperatur | 0 - 40 °C |
Storage temperature range | -20 - 70 °C |
Operating relative humidity | 0 - 90% |
humidity during storage | 0 - 95% |
operating height | 0 - 3000 m |
weight and dimensions | |
broad | 236 mm |
depth | 102 mm |
height | 27 mm |
Weight | 600 g |
certificates | |
certification | CE, FCC, ICES-003, VCCI, RCM, BSMI, KC, CB, CE LVD, BSMI, EAC, RCM, KC, EN 60950-1 |
logistic data | |
Goods tariff number (HS) | 85176990 |
