Certification | UL, cUL, UL-EU, RoHS |
LED indicators | Yes |
Rack mounting | Yes |
Stackable | Yes |
Product colour | Grey |
Form factor | 1U |
Safety | UL60950-1, CAN/CSA-C22.2 # 60950-1-03, EN60950-1, EN60825-1, AS/NZS 60950.1 |
Electromagnetic compatibility | EN55022 A, FCC A, VCCI A |
AC input voltage | 100 - 240 V |
Input current | 2.4 A |
AC input frequency | 50 - 60 Hz |
Power consumption (max) | 26 W |
MAC address filtering | Yes |
Security algorithms | HTTPS |
SSH/SSL support | Yes |
Authentication | MAC-based authentication, Port-based authentication |
BPDU filtering/protection | Yes |
Access Control List (ACL) | Yes |
Loop protection | Yes |
DHCP features | DHCP client |
IGMP snooping | Yes |
Storage temperature (T-T) | -25 - 70 °C |
Storage relative humidity (H-H) | 5 - 95% |
Heat dissipation | 89 BTU/h |
Operating relative humidity (H-H) | 5 - 90% |
Operating altitude | 0 - 3048 m |
Operating temperature (T-T) | 0 - 50 °C |
Web-based management | Yes |
Quality of Service (QoS) support | Yes |
System event log | Yes |
Switch type | Managed |
Switch layer | L3 |
Traffic classification | Yes |
MIB support | SNMP |
ARP inspection | Yes |
Width | 341 mm |
Depth | 231 mm |
Height | 44 mm |
Weight | 2.4 kg |
Networking standards | IEEE 802.1Q |
10G support | Yes |
VLAN support | Yes |
Copper ethernet cabling technology | 10GBASE-T |
Virtual LAN features | Private VLAN |
IP routing | Yes |
Flow control support | Yes |
Full duplex | Yes |
Broadcast storm control | Yes |
Port mirroring | Yes |
Rate limiting | Yes |
Link aggregation | Yes |
Spanning tree protocol | Yes |
Active link detection | Yes |
INTERNAL MEMORY | 256 MB |
Flash Memory | 64 MB |
Memory type | DDR-SDRAM |
Noise level | 34 dB |
Physical stacking (units) | 32 |
Supported network protocols | IPv6, IPv4, DHCP, NTPv6, STP, BDPU, IP, ICMP, ARP, LLDP, SNMP, MSTP, RSTP, RIP, TLS,TTLS,PEAP, MD5, Telnet, GVRP |
Management protocols | SNMP |
Basic switching RJ-45 Ethernet ports quantity | 24 |
COMPATIBLE MEMORY CARDS | SD |
Fiber optic connector | SFP |
Basic switching RJ-45 Ethernet ports type | Gigabit Ethernet (10/100/1000) |
SFP module slots quantity | 4 |
console port | RJ-45 |
Number of queues | 8 |
Switching capacity | 56 Gbit/s |
Throughput | 41.7 Mpps |
Jumbo Frames support | Yes |
MAC Address Table | 16000 entries |
Jumbo frames | 10000 |
Packet buffer memory | 1.5 MB |
Power Over Ethernet (PoE) | No |
Multicast support | Yes |
Transmission distance (max) | 80 km |
Fiber ethernet cabling technology | 1000BASE‑LX |
