Product colour | Black |
LED indicators | Activity |
Stackable | Yes |
Power supply included | Yes |
Power source | DC |
Power consumption (typical) | 4.918 W |
DC input voltage | 12 V |
Input current | 1 A |
IGMP snooping | Yes |
Operating relative humidity (H-H) | 10 - 90% |
Storage relative humidity (H-H) | 5 - 90% |
Storage temperature (T-T) | -10 - 70 °C |
Operating temperature (T-T) | 0 - 40 °C |
Heat dissipation | 16.78 BTU/h |
Quality of Service (QoS) support | Yes |
Switch layer | L2 |
Switch type | Unmanaged |
Height | 28 mm |
Depth | 82 mm |
Weight | 238.6 g |
Width | 100.5 mm |
Networking standards | IEEE 802.3u |
10G support | No |
Auto MDI/MDI-X | Yes |
Flow control support | Yes |
MAC address auto-learning supported | Yes |
Fanless | Yes |
Mean time between failures (MTBF) | 765190 h |
Compliance certificates | Low Voltage Directive (LVD) |
2.5G Ethernet (copper) ports quantity | 5 |
Basic switching RJ-45 Ethernet ports type | 2.5G Ethernet (100/1000/2500) |
Basic switching RJ-45 Ethernet ports quantity | 5 |
Forwarding rate | 18.6 Mpps |
Switching capacity | 25 Gbit/s |
Store-and-forward | Yes |
MAC Address Table | 4000 entries |
Packet buffer memory | 8.1 MB |
Power Over Ethernet (PoE) | No |
Multicast support | Yes |
Sustainability compliance | Yes |
