| Number of fans | 2 fan(s) |
| Stackable | Yes |
| Safety | cUL, CB |
| Rack mounting | Yes |
| LED indicators | Speed |
| Product colour | Grey |
| Power supply included | Yes |
| Power consumption (max) | 436.3 W |
| Power source | AC |
| AC input voltage | 100 - 240 V |
| Authentication | MAC-based authentication, Port-based authentication |
| DHCP features | DHCP server |
| BPDU filtering/protection | Yes |
| IGMP snooping | Yes |
| SSH/SSL support | Yes |
| Access Control List (ACL) | Yes |
| Access Control List (ACL) rules | 768 |
| Security algorithms | SSH-2 |
| Heat dissipation | 1487.78 BTU/h |
| Storage relative humidity (H-H) | 0 - 95% |
| Storage temperature (T-T) | -20 - 70 °C |
| Operating temperature (T-T) | -5 - 50 °C |
| Operating relative humidity (H-H) | 0 - 95% |
| Switch layer | L2/L3 |
| System event log | Yes |
| Switch type | Managed |
| Traffic classification | Yes |
| Quality of Service (QoS) support | Yes |
| Depth | 308.5 mm |
| Width | 440 mm |
| Height | 44 mm |
| Weight | 4.25 kg |
| Copper ethernet cabling technology | 10BASE-T |
| Auto-negotiation | Yes |
| Flow control support | Yes |
| Spanning tree protocol | Yes |
| Broadcast storm control | Yes |
| Number of VLANs | 4094 |
| Virtual LAN features | Protocol-based VLAN |
| MAC address auto-learning supported | Yes |
| Head-of-line (HOL) blocking | Yes |
| Cable types supported | Cat5 |
| Full duplex | Yes |
| Port mirroring | Yes |
| 10G support | Yes |
| VLAN support | Yes |
| Link aggregation | Yes |
| Auto MDI/MDI-X | Yes |
| Networking standards | IEEE 802.3at |
| Built-in processor | Yes |
| Mean time between failures (MTBF) | 274796 h |
| INTERNAL MEMORY | 256 MB |
| Flash Memory | 32 MB |
| Processor frequency | 400 MHz |
| Package depth | 510 mm |
| Package width | 450 mm |
| Package height | 121 mm |
| PACKAGE WEIGHT | 7.06 kg |
| SFP+ module slots quantity | 4 |
| Basic switching RJ-45 Ethernet ports quantity | 24 |
| Fiber optic connector | SFP+ |
| Basic switching RJ-45 Ethernet ports type | Gigabit Ethernet (10/100/1000) |
| Harmonized System (HS) code | 85176990 |
| Jumbo Frames support | Yes |
| MAC Address Table | 16384 entries |
| Store-and-forward | Yes |
| Jumbo frames | 9216 |
| Switching capacity | 128 Gbit/s |
| Throughput | 95.24 Mpps |
| Number of queues | 8 |
| Packet buffer memory | 1.5 MB |
| Total Power over Ethernet (PoE) budget | 370 W |
| Power over Ethernet (PoE) ports quantity | 24 |
| Power over Ethernet (PoE) power per port | 30 W |
| Power Over Ethernet (PoE) | Yes |
| Multicast support | Yes |
